3/4 Axis CNC 3040 6040 6090 Router Engraver USB Port Milling Engraving Machine. MODEL ONE:USB 4 Axis CNC 6090 Router 2200W. CNC 6090 router 4Axis+2.2kw Spindle motor +VFD +USB Port Metal Wood Engraver with. CNC Router engraving machine parameters. Outside dimension:1150x970x650mm(LxWxH). Working platform size:1045x720mm(LxW). Frame Material:The whole machine used 6061 aluminum profiles. Feeding height:? 140mm(From base of Z axis to platform). X, Y, Z Working Area:600x900x150mm. Sliding unit:X axis:SFU1605 Ball Screws;Y axis:SFU1605 Ball Screws;Z axis:SFU1204 Ball Screws. Drive unit:X axis:ø20 High intensity round rail, Y axis: SBRø20 high-strength aluminum base rails;Z axis: ø12 high-strength round rail. Stepping motor:two-phase 3A (with handwheels). Driving Power for Stepping motor:AC110,240W, Output DC24V10A. Maximum Idle speed:1500mm/m. Working Speed:50-1500mm/min (different material with different speed settings). Spindle motor:2200Whigh-speed variable frequency spindle motor, ER11 chuck, matching 6mm bur. Variable-frequency Drive(VFD):AC110V, 2200W, 0-400Hz(built-in Control box). Tips:1, The spindle motor must connect with the VFD. 2, It cannot directly connect with the supply voltage (AC110V/220V). 3, Please don’t change the data setting of the VFD if you are not professional technicians, or it might damage the spindle motor. Drive of Stepping motor. 0-3.5A adjustable four-axis driveTB6560AHQchip, 24V power supply, 2,4,8,16Subdivision. Settings, Factory setting:8subdivided. Repositioning precision:? 0.05mm. Cooling method:Water cooling, Matching heat dissipation water pump. Spindle precision:Radial runout? 0.03mm. Carving command:G code/TAB file/nc/TAB /NCC/file. Protection:Emergency stop button. Communication interface:through USB PORT connect with computer. Support system:Windows XP / win7 with 32bite. Gross weight of machine. Update function: with limit switch. Woodworking industry: sculpture, round carving, wooden handicraft processing. Advertising signs: logo making, cutting acrylic, plastic molding, suit for making a variety of materials advertising decorative products. Other industries: The engraver could do shadow-carved, sculpture which widely used in the gift industry; can be used in aluminum cutting industry, such as aluminum, aluminum-plastic plate, aluminum honeycomb panels, aluminum, 3D engraving process, Artificial plate, cutting LED and neon letter, making plastic light box model; also can engrave on acrylic, copper, PVC board, artificial stone, MDF board, and other metal sheet. 1, The NEW 2.2KW water-cooled VFD is available operating for long time, which can reinforced the processing ability of the machine and can be used to engrave on aluminum alloy and hard wood. 2, water cooling spindle works more stable and durable. 3, High quality accurate ball Screws drive make the engrving more precision. Anti-blackflash, high precision, long life circle. Assembling and locating the CNC machine on steady desk well. Make sure that your computer has a USB port output. Place the control box in a ventilated dry place where there is no dust, no moisture. Connecting the control box with the CNC machine and you computer and make sure the plug will not come off. Correctly connect the machine with the controller. Don’t suspended the cable which connect the Spindle motor with axis(X, Y, Z, A). Damage the driver of the controller. Correctly instal the Spindle motor and the heat pump. The heat pump should be covered completely in the water, then turned on the electric current to. Check whether the water-cooling system working well. Before turn on the machine, please check all the cable and water- cooling system to make sure they are working fine. You can enjoy making you dream with using our CNC machine now. 1X main unit (Frame). 1X main unit (working base). 1X Sinal cable for A axis. 10X 47mm round head. 6X 410mm black Inner six angle screw with nut. 8X 520mm black Inner six angle screw. 4X 58mm Flat Philip’s head screw with nut and gasket. 8X 624mm BALCK FLAT Inner six angle screw. 2X six angle Wrench(3mm). 2X six angle Wrench(4mm). 1x Tools Setting Auto-Check Instrument for CNC. MODEL TWO:USB 4 Axis CNC 6090 Router 1500W. 4Axis USB 1500W CNC Router Engraving Machine Engraver For Wood Acrylic 6090 Ball Screw. Model: CNC6090GZ Outside dimension: 1150970650mm(LWH) Working platform size: 1045720mm(LW) Frame Material:The whole machine used 6061 aluminum profiles Max. Feeding height:? 140mm(From base of Z axis to platform) X, Y, Z Working Area: 900(Y)600(X)140mm(Z). X axis:SFU1605 Ball Screws Y axis:SFU1605 Ball Screws Z axis:SFU1204 Ball Screws. X axis: ø20 High intensity round rail, Y axis: SBRø20 high-strength aluminum base rails Z axis: ø12 high-strength round rail Stepping motor: 57 two-phase 3A (with handwheels) Driving Power for Stepping motor: AC110, 240W, out put: DC24V, 10A Maximum Idle speed: 1500mm/min Working Speed: 50-1500mm / min (different material with different speed settings) Spindle motor: 1500W high-speed variable frequency spindle motor, ER11 chuck, with 6mm collet. The spindle motor must connect with the VFD. It cannot directly connect with the supply voltage (AC 110V). Please don’t change the data setting of the VFD if you are not professional technicians, or it might damage the spindle motor. Drive of Stepping motor: 0-3.5A adjustable four-axis drive (TB6560AHQ chip, 24V power supply, 2,4,8,16 subdivision can be set, factory settings 8 subdivision) Repositioning precision:? 0.05mm Cooling: Water-cooling Speed: 0-24000r/m Spindle precision: Radial runout? 0.03mm Carving command: G code / TAB file / nc file / NCC file VFD: AC110V, 1500W, 0-400Hz (built-in control box). USB Control box parameters. Protection: Emergency stop button Communication interface: through USB PORT connect with computer Support system: Windows XP / win7 with 32 bit. Input Volts: AC 110V. Woodworking industry: sculpture, round carving, wooden handicraft processing Advertising industry: advertising signs, logo making, cutting acrylic, plastic molding, suit for making a variety of materials advertising decorative products Other industries: The engraver could do shadow-carved, sculpture which widely used in the gift industry; can be used in aluminum cutting industry, such as aluminum, aluminum-plastic plate, aluminum honeycomb panels, aluminum, 3D engraving process, Artificial plate, cutting LED and neon letter, making plastic light box model; also can engrave on acrylic, copper, PVC board, artificial stone, MDF board, and other metal sheet. The NEW 1.5KW water-cooled VFD is available operating for long time, which can reinforced the processing ability of the machine and can be used to engrave on aluminum alloy and hard wood. Water cooling spindle works more stable and durable. High quality accurate ball Screws drive make the engrving more precision. Otherwise, it will damage the driver of the controller. The heat pump should be covered completely in the water, then turned on the electric current to check whether the water-cooling system working well. MODEL Three:USB 4 Axis CNC 6040 Router 1500W. 1X 25pin Parallel lines. Notes:Please prepare a computer with DB25 parallel Interface. Suitable for PCB, wood, Plexiglass, PVC, Crystal Acrylic, RESIN, Plastic, SEALS, MDF, COMPOSITE. Aluminum material, Copper, Iron. This CNC 6040T machine is suitable for industry, Technology Research, Advertising Design. Arts Creation, Teaching, Student Project and Hobby Purposes. It can work with various materials(metallic & non-metallic), such as: wood, pmma or other. Plastic, MDF board, native wood, PVC, Acrylic, wood, composite. Like aluminum, copper and silver to engrave them into. It can used for engraving: advertising signs, PCB, nameplates, badges, seals, bronzing plate, aluminum alloy, acrylic plates, ABS resin double color plate. PVC foaming board, indentation plates, signs, construction models, instrument panels, wooden products, etc. The mini CNC router Frame is movable. The machine can connect with computer as other. External device such as printer, scanner.. With the assist of the CNC ROUTER 6040T, your design idea will be real-time display. CNC Engraving Machine Parameters. X, Y, Z Working Area : 600(Y)390(X)120(Z)mm. Lathe structure : 6061/6063 Aluminum alloy. X axis :1605 Ball Screws. Y axis :1605 Ball Screws. Z axis:1204 Ball Screws. X axis:High intensity Chromeplate shaft. Y axis:High intensity Chromeplate shaft. Z axis:High intensity Chromeplate shaft. 1, The spindle motor must connect with the VFD. 2, It cannot directly connect with the supply voltage (AC110V). 3, Please don’t change the data setting of the VFD if you are not professional technicians. Or it might damage the spindle motor. Material:304 stainless steel, Copper coil, Pressure cast aluminum pipe water jacket. AC110V-220V/50Hz, 5A, 1.5KW VFD. Spindle speed : 24000 rpm. Max working frequency : 400Hz. Principal axis collet: ER11collet, Standard configuration :6mm. Speed mode:By adjusting the VFD output voltage and operating frequency. Lubrication way: lubricated by high grease. Repeat accuracy:0.05mm. Spindle precision:radial beat acuities 0.03mm. Carving Instructions: G code / TAB files / nc file / NCC files. Communication interface:through USB connection with computer. Support system: Windows XP WIN7. Maximum Idle speed:1500mm/min. Working Speed :50-1500mm / min (different material with different speed settings). Control unit:Toroidal transformer + PWM power supply module + TB6560 stepping motor drive. Command code:G code. 1, The NEW 1.5KW water-cooled VFD is available operating for long time, which can reinforced the processing abilty of the machine and can be used to. Process aluminum alloy and hard wood. Make sure that your computer has a 25pin parallel port output. Place the contral box in a ventilated dry place where there is no dust, no moisture. MODEL FOUR:USB 3 Axis CNC 6040 Router 1500W. 3 AXIS CNC Router 6040 Engraver Engraving Mill&Drill 3D. Suitable for PCB, wood, Plexi glass, PVC, Crystal Acrylic, RESIN, Plastic, SEALS, MDF, COMPOSITE, Aluminum material, Copper. This CNC 6040 machine is suitable for industry, Technology Research, Advertising Design, Arts Creation, Teaching, Student Project and Hobby Purposes. It can work with various materials(metallic & non-metallic), such as: wood, pmma or other plastic, MDF board, native wood, PVC, Acrylic, wood, composite board plywood. Like aluminum, copper and silver to engrave them into 3D/2D works etc. It can used for engraving: advertising signs, PCB, nameplates, badges, seals, bronzing plate, aluminum alloy, acrylic plates, ABS resin doublecolor plate, PVC foaming board, indentation plates, signs, construction models, instrument panels, wooden products, etc. The machine can connect with computer as other external device such as printer, scanner.. Cnc engraving machine parameters. X, Y, Z Working Area: 600(Y)390(X)120(Z)mm Outside dimension: 865680570mm(LWH) Table size: 770(Y)490(X)mm Lathe structure: 6061/6063 Aluminium alloy Max. It cannot directly connect with the supply voltage (AC220V). Outside dimension: 65158mm Material: 304 stainless steel, Copper coil, Pressure cast aluminum pipe water jacket VOLTS, current, power: AC110 /60Hz, 5A, 1.5KW VFD Spindle speed: 24000 rpm Max working frequency: 60Hz Principal axis collet: ER11collet, Standard configuration :6mm Nut Model: ER11-A Cooling: Water-cooling Speed mode: By adjusting the VFD output voltage and operating frequency from 0-24000RPM Lubrication way: lubricated by high grease Repeat accuracy: 0.05mm Spindle precision: radial beat acuities 0.03mm Carving Instructions: G code / TAB files / nc file / NCC files Communication interface: through USB connection with computer Support system: Windows XP/Win7. Operating Voltage: AC110V Control unit: Toroidal transformer + PWM power supply module + TB6560 stepping motor drive Computer connection: USB port Command code: G code. Protection: Emergency stop button. The NEW 1.5KW water-cooled VFD is available operating for long time, which can reinforced the processing abilty of the machine and can be used toprocess aluminum alloy and hard wood. Place the contral box in a ventilated dry place where there is no dust, no moisture 4. Otherwise, It will damage the driver of the controller. Before turn on the machine, please check all the cable and water-cooling system to make sure they are working fine. If you have any problem. MODEL Five:USB 4 Axis CNC 3040 Router 800W. 4Axis CNC Router 3040 Engraver Dril Milling Machine spindle motor VFD USB. CNC ROUTER ENGRAVING MACHINE ENGRAVER 3040 COOL SPINDLEMOTOR VFD 800W USB PORT. CNC ENGRAVING MACHINE parameters. X, Y, Z Working Area: 400(Y)295(X)80(Z)mm. Lathe structure: 6061/6063 Aluminium alloy. X axis—SFU01204-4 Ball Screws. Y axis—SFU01204-4 Ball Screws. Z axis—SFU01204-4 Ball Screws. X axis—High intensity Chromeplate shaft. Y axis—High intensity Chromeplate shaft. Z axis—High intensity Chromeplate shaft. It cannot directly connect with the supply voltage (220V). Material: 304 stainless steel, Copper coil, Pressure cast aluminum pipe water jacket. VOLTS, current, power: AC220V, 50Hz, 5A, 0.8KW VFD. Spindle speed: 24000 rpm. Max working frequency: 400Hz. Principal axis collet: ER11collet, Standard configuration:6mm. Speed mode: By adjusting the VFD output voltage and operating frequency from 0-24000RPM. Repeat accuracy: 0.05mm. Spindle precision: radial beat acuities 0.03mm. Communication interface: through USB connection with computer. Support system: windows XP / win7,32Bits. Carving speed: 0-2500mm/min(different materials differ). Control unit: Toroidal transformer + PWM power supply module + TB6560 stepping motor drive. Computer connection: USB port. Command code: G code. 8X 611mm BALCK FLAT Inner six angle screw. This CNC 3040T machine is suitable for industry, Technology Research, Advertising. Design, Arts Creation, Teaching, Student Project and Hobby Purposes. And soft metal, like aluminum, copper and silver to engrave them into 3D/2D works etc. It can used for engraving: advertising signs, PCB, nameplates, badges, seals, bronzing plate, aluminum. Alloy, acrylic plates, ABS resin double color plate, PVC foaming board, indentation plates, signs, construction models, instrument panels, wooden products, etc. With the assist of the CNC ROUTER 3040T, your design idea will be real-time display. The NEW 0.8KW water- cooled VFD is available operating for long time, which can reinforced the processing. Abilty of the machine and can be used to process aluminum alloy and hard wood. Anti- blackflash, high precision, long life circle. Connecting the control box with the CNC machine and you computer and make sure the plug will. Don’t suspended the cable which connect the. Spindle motor with axis(X, Y, Z, A). MODEL SIX:USB 4 Axis CNC 3040 Router 400W. 4 AXIS 3040 400W. More Precise Stepping Motor. The engraving process is visible as controlled by computer. Simple operation and installation. CNC 3040 is suitble for Industry, Technology Research, Advertising Design, Arts Creation, Teaching, Student Project and Hobby Purposes. CNC3040 is a desktop CNC machine and designd for processing Industrial or Hobby Prototype Building, Building Model Making, PCB. Adverstising Signs, Artwork, Crafts, Aircraft Models, RC Model parts, etc. So, you can do engraving work at office or home. Exquisite 3040 is a miniature version of mobile longmen structure of carving machine, put on you computer is like puting a printer or scanner that coordination, and can completely as a compute peripherals tools, anywhere, anytime, help you to design intent fast real appear. Nonmetal materials on the milling, and it can also be used to carving simple PCB/CNC. This 3040 engraer is a user-friendly desktop engraving machine for those with limited space and /or a limited budget. The Computerized CNC Engraving and Cutting Machine is suitable for various materials, such as WOOD, PMMA or other plastic. MDF board, native wood, PVC, Acrylic, wood, composite board plywood, It can be used widely to process or make adverstising signs, PCB. Nameplates, badges, seals, bronzing plate, aluminium alloy, acryplates, ABS resin double color plate, PVC foaming board, indentation plates, signs. Construction models, instrument panels, wooden products, etc. Effective working travel:275(X)mm385(Y)mm60(Z)mm. Work table dimension:320mm530mm. Frame materials:aluminum alloy 6063 and 6061. Leadscrew:1404 double thread Trapezoidal screws. Driving units:X axis:1204 trapezoidal screws. Y axis:1204 trapezoidal screws. Z axis:1204 trapezoidal screws. Sliding units:X axis:Dia. 16mm chrome plate shafts. 12mm chrome plate shafts. Stepping motor type:57 two-phase 1.8A. Spindle motor:400w dc motor 5008000PRM/Min. Principal axis collet:ER11 / 3.175 mm. Spindle precision:radial beat acuities 0.03 mm. Control unit:triaxial one-piece drive + ring variable power + PWM speed. Communication interface:USB PORT. Support system:windows XP / win7, 32Bits. Control unit:2.5A stepping motor driver plus adjustable spindle speed controller. Computer connection:USB port. Make sure that your computer has a on-board USB port output. Connecting the control box with the CNC machine and you computer. MODEL SEVEN:USB 4 Axis CNC 3020 Router 300W. 3020T 4AXIS CNC ROUTER ENGRAVER DRILL MILLING MACHINE 3D CUTTER ARTWORK. Item Units and Pictures (what you see what you get). CNC 3020 is suitble for Industry, Technology Research, Advertising Design, Arts Creation, Teaching, Student Project and Hobby Purposes. CNC 3020 is a desktop CNC machine and designd for processing Industrial or Hobby Prototype Building, Building Model Making, PCB, Adverstising Signs, Artwork, Crafts, Aircraft Models, RC Model parts, etc. So, you can do engraving work at office or home. Exquisite 3020 is a miniature version of mobile longmen structure of carving machine, put on you computer is like puting a printer or scanner that coordination, and can completely as a compute peripherals tools, anywhere, anytime, help you to design intent fast real appear. Engrave almost anything on almost any surface. X? Y? Z axis carving make more precise and and three-dimensional effect. Cover plates reducing pollution for the screws and shafts. More steady and strong equiped with aluminum alloy frame materials. Reinforced and thickened machine body make transportation absolutely to be safer and longerlife time. This 3020 engraer is a user-friendly desktop engraving machine for those with limited space and /or a limited budget. The Computerized CNC Engraving and Cutting Machine is suitable for various materials, such as WOOD, PMMA or other plastic, MDF board, native wood, PVC, Acrylic, wood, composite board plywood, It can be used widely to process or make adverstising signs, PCB, nameplates, badges, seals, bronzing plate, aluminium alloy, acryplates, ABS resin double color plate, PVC foaming board, indentation plates, signs, construction models, instrument panels, wooden products, etc. 3020T triaxial engraving machine part parameters. Effective working travel : 200(X)mm300(Y)mm45(Z)mm. Frame materials : aluminum alloy 6063 and 6061. X axis 1204 trapezoidal screws. Y axis 1204 trapezoidal screws. Z axis 1204 trapezoidal screws. 13mm chrome plate shafts. Stepping motor type : 57 two-phase 1.45A-2A. Spindle motor: 300w dc motor. Principal axis collet: ER11/3.175 mm. Spindle speed : 300 8000rpm/min (PWM stepless speed regulation). Empty line speed: 0-2500mm/min (16 subdivided driving down). Spindle precision: radial beat acuities 0.03 mm. Control unit: triaxial one-piece drive + ring variable power + PWM speed. Carving Instructions: G code/TAB files/nc file/NCC files. Communication interface through USB Port with computer. Support system : Windows 7/ xp. Carving speed: 0-2000mm/min (different materials differ). Control unit :2.5A stepping motor driver plus adjustable spindle speed controller. Command code G code. Protection Emergency :stop button. Can be controlled by computer. Can control the engraving more precise. Emergency stop button enhance security. Large 3D engraving in soft wood, MDF board, native wood, PVC, Acrylic we suggest use one or two spiral flute ball bits. Can engraving much more materails by spiral flute bits, such as metal, steel, MDF board, solid wood, composite board plywood, stone. Spindle motor knob is useful for small positioning adjustment, with steady and strong support structure. The reinforced and thickened machine body make transportation absolutely to be safer and longer life time. The chrome shafts is not easy to deform, suitable for long time use. Flexible coupling can be used for high torque transmission. High Precision Stepping motor makes engraving more precise. 32-bit version of Windows 2000, Windows XP, Windows Vista, or Windows 7 (64-bit versions will not work). Non-integrated Video Card with 32MB RAM(Large G-code files, especially 3D files will require a video card with 512MB RAM or higher). MODEL Eight:USB 3 Axis CNC 3040 Router 400W. USB CNC ROUTER 3 axis 3040 400W ENGRAVER/ENGRAVING MILLING M/C 110AV. Reinforced and thickened machine body make transportation absolutely to be safer and longer life time. CNC3040 is suitble for Industry, Technology Research, Advertising Design, Arts Creation. Teaching, Student Project and Hobby Purposes. CNC3040 is a desktop CNC machine and designd for processing Industrial or Hobby. Prototype Building, Building Model Making, PCB. Adverstising Signs, Artwork, Crafts, Aircraft Models, RC Model parts, etc. So, you can do. Engraving work at office or home. Exquisite 3040 is a miniature version of mobile longmen structure of carving machine. Put on you computer is like puting a printer or scanner that coordination, and can. Completely as a compute peripherals tools, anywhere, anytime, help you to design intent fast real appear. This 3040 engraer is a user-friendly desktop engraving machine for those with limited space. And /or a limited budget. The Computerized CNC Engraving and Cutting Machine is suitable for various materials. Such as WOOD, PMMA or other plastic. MDF board, native wood, PVC, Acrylic, wood, composite board plywood, It can be used. Widely to process or make adverstising signs, PCB. Nameplates, badges, seals, bronzing plate, aluminium alloy, acryplates, ABS resin double. Color plate, PVC foaming board, indentation plates, signs. 3040T triaxial engraving machine part parameters. Effective working travel :275(X)mm385(Y)mm70(Z)mm. Work table dimension :320mm530mm. Frame materials :aluminum alloy 6063 and 6061. Leadscrew :1404 double thread Trapezoidal screws. X axis:1404 trapezoidal screws. Y axis:1404 trapezoidal screws. Z axis:1404 trapezoidal screws. Stepping motor type :57 two-phase 1.8A. Spindle motor :400w dc motor 5008000PRM/Min. Principal axis collet :ER11 / 3.175 mm. Repeat accuracy :0.05mm. Spindle precision :radial beat acuities 0.03 mm. Control unit :triaxial one-piece drive + ring variable power + PWM speed. Communication interface :through USB Port with computer. Support system :windows XP / win7. Operating Voltage: AC110V US PLUG. Control unit: 2.5A stepping motor driver plus adjustable spindle speed controller. Computer connection: on board palrallel port. Installment Support system is simple and intellgent. Feedback is very important to us. It is impossible to address issues if we do not know about them! Faction is our ultimate goal. We work hard to earn your trust and future business. A If you receive a defective item, you may return it or ask for a discount. Due to time zones, our reply to your questions may not be immediately. If it’s non-workdays, please kindly be patient and wait till Monday.

ULTIMATE Bee CNC Router Machine – SFS1210 Ball Screw Transmission. 1500x1500mm ULTIMATE Bee CNC Mechanical Kit (Silver Extrusion). Quiet Transmission High Precise SFS1210 Ball Screws and Nuts. New Design Cable Drag Chain System. 4Pcs x 2.45N. M High-Torque Nema23 Stepper Motors. BULK-MAN 3D ULTIMATE Bee. Is a solid and reliable CNC Machine. HGR Rails and Quiet Transmission Ball Screws. Bee CNC excels at cutting through. Plastics, foam, softwood, hardwood and even soft metal such as aluminium and brass. Is our second CNC Machine based on the initial. Design lineage, which is characterised by the use of C-Beam. 100% fully self-developed, designed by BulkMan3D International R&D Team and copyrighted. SFS1210 Ball Screw + HGR Linear Rails. Maximum Supported weight of Z-Axis(spindle). (Tested with? 80 1.5KW spindle). Z-Axis: 150-180mm/5.9-7.1inch. 1.5 year online support. The Ball screw nut fixing and dismounting requires professional tools or done by professional stuffs! Never rotate the ball screw nut over the ball screw end! ULTIMATE Bee Breif Introduction. Bulk-Man 3D is the largest wholesaler of Open Source CNC parts worldwide. By producing or sourcing parts directly from the factory. We eliminate the “middle man”, and in doing so, we can provide. The best wholesale price direct to the public! After many CNC owners and members of the community approached us requesting a linear rail solution for their machine at an affordable price. Our technicians worked hard researching different. Options available and ways we can improve on existing designs. The result of the project was. Carrying on the tradition of community engagement, CNC owners and members wanted more, our technicians went back to the drawing board. Researching more improvements based on community. Input, the resulting machine is the. Mainly distinguishes itself from the first design, the. By having Ball Screws as a transmission system instead. Of the traditional ACME Lead Screw. Screw has high-efficiency levels, delivering more torque to the motor when compared to an ACME Lead. Screw used in the. Is not only a machine capable of cutting through a wide diversity of materials. The ULTIMATE Bee excels at cutting. Compatible Material for Cutting/Milling/Engraving. Aluminium / Hard Wood / Soft Wood / Oak / Plexi Glass / Delrin / HDPE / Foam. Drill Bits & Milling Cutters. The ULTIMATE Bee can create intricate 3D carvings like wood artware, inlays, adverting logo, plaques. Furniture, amazing art works and so much. All the widely used applications can be achived here! Recommended Waste Board Dimensions(mm). The ULTIMATE Bee was designed by our team of engineers with a great amount of thought into each aspect of the machine. Each of the components used. On our machine are designed to be. Paired with each other in order to create a perfect ecosystem which results in the ULTIMATE Bee CNC Machine. Don’t be tricked by other companies who claim a larger ball screw, more rails/ bearings, or different rail positioning will make their machine better than the. Made with no engineering reason or facts by salesmen, not engineers. By researching the specifications of the. Components, you can conclude that in fact larger ball screws, more rails/bearings. Different rail positioning all reduce a machine’s performance. Ball Screw Size Engineered For Our Machines. The ULTIMATE Bee features a 12mm Diameter Ball Screw. The 12mm Diameter Ball Screw was carefully selected by our engineers to make the most of a NEMA 23 stepper motor. Just by having this smaller diameter than a 16mm Ball Screw, it reduces the load on the motor by 25%. In other words, when the NEMA 23 Stepper motor is paired with the 12mm Ball Screw the motion motors drive through tougher materials with up to 25% more torque than the same motors paired with a 16mm Ball Screw. Why Do You Get More Torque Out of a 12mm Ball Screw? The reason is very simple: the further you apply the force to the pivot point, the more impact this force will have on the pivot object. On a CNC, the stepper motor shaft is the pivot point, and the distance where the force is applied to the shaft is determined by the diameter of the Ball Screw. The analogy in the image below helps explain why a smaller diameter Ball Screw can be more effective. Bigger Ball Screws are recommended when they are designed to work with larger motors such as NEMA 34, or AC Servo motors for the transmission system to compensate for the extra torque required. Machines of this caliber would also use cast and milled steel frames rather than aluminum profiles. A Ball Screw larger than 12mm should not be used in a design where the motors are NEMA 23. What About The Vibration On a Smaller Diameter Ball Screw? Keeping low-vibration levels in the transmission system is extremely important for a CNC Machine. Due to this, we have paired the ULTIMATE Bee with a 10mm pitch Ball Screw instead of a usual 4mm pitch for the X and Y-Axis. This change has significant results, making the CNC travel more with smaller Ball Screw rotations, thus, reducing the Ball Screw vibration at fast feed rates. Our engineering tests conclude: A 12mm ball screw has the perfect balance of torque and vibration when paired with a NEMA 23 motor in a CNC Machine size 1500x1500mm or less. Larger Ball Screws are an incorrect design for NEMA 23 Motors. That is why the ULTIMATE Bee is the best design of its kind! 2 Rails Is Better Than 4. Simpler Design, Better Results! The correct number of linear rails and bearings were selected by our engineers to increase performance. The HGH15CA bearings used on the X and Y-Axis were designed to have the correct spacing between them when mounted to a 20 series profile. The Y-Axis each utilise a single HGR15 linear rail with 2 x HGH15CA bearing carriages on the gantry plates. In a system where only the friction caused by bearings is considered, having double rails and bearings on the Y-Axis as per the image below will add an additional +100% of the amount of friction, therefore, more motor power will be required. If you pair this with any minute misalignment of a bearing or rail during installation, the force required by the same motor to move 4 bearings will result in loss of motor power which is translated to a loss in performance. Of a machine that uses 2 rails (4 bearings) on one actuator. Because the X-Axis gantry carries the Z assembly the moment loads (MR in particular) are distributed by using 4 x HGH15CA bearing carriages and 2 x HGR rails. The Z-Axis uses 2 x MGN15 Linear Rails and 4 x MGN15C carriages spaced to obtain maximum. Possible resistance to the operational moment loads (MP in particular). In other words, we reverse engineered the forces that the Z-Axis is subjected to during a cutting operation, and then, calculated the necessary spacing between MGN bearings for the Z-Axis. NOTE: The position of the Ball Screws, Linear Rails and Bearing Carriage are designed for optimal positioning on all axis (Y, A, X and Z) – another. Example of Bulk Man 3D engineering innovation. Opposite bearing designs are a flaw. The opposite bearing design implemented by other competitors is an inferior and incorrect engineering design for the X-Axis. The correct design is where t. He rails and bearings are on the same face because the bearings are less susceptible to twisting from moment forces when paired with another set of. The opposite bearing design is more susceptible to twisting especially when paired with heavy spindles such as the 2.2kW. The moment force subjected t. O the bearings in this configuration will induce more runout, meaning worse tolerances compared to a stronger and correctly engineered design that has bearings on the same face. Correct Couplers Used In ULTIMATE Bee Design. Double diaphragm couplings are designed for ball screws while jaw couplings are not designed for ball screws. Double Diaphragm couplings are more efficient than Jaw Couplings when paired with ball screws as they are designed for zero backlash. The diaphragm coupling design uses metal plates rather than plastic, making them more reliable and yield a longer service life. The double diaphragm coupling allows for higher speed and vibration dampening in the system which is essential for high performance and smooth running of the CNC. Smooth operation with little to no vibration will mean smoother and high-quality cuts. A design which uses a Jaw Coupling with a Ball Screw is an incorrect engineering design and will produce poor finish on the work piece. Ball Nut Gaskets Reduce Vibration and Binding. Giving the ball nut a vibrational buffer in the form of a rubber gasket, the. Ball screw remains centered by. Damping the vibrational forces acting on. This provides precision results and prevents the axis. This small addition make the ULTIMATE Bee a far more effective system. In order to get the most out of your. Machine without the worry of damage. Or chatter on your workpiece. Extra Z-Axis Height Increases Work Possibilities. Our machines offer 180mm of Z-axis workspace to maximize the working potential. It is easy to mill out large cuts of wood, plastic or aluminium or add a r. When our engineers designed the ULTIMATE Bee we took our customer’s feedback on wanting extra workable height as a main consideration. His way, there will be no need to make. Upgrades or additions later to achieve more cutting depth, or space to add a new rotary axis. The ULTIMATE Bee, The Best and Last of its Kind! Coming from the WorkBee lineage, the ULTIMATE Bee was thoroughly designed to be the best and last of its kind. No need for versions 2, 3 and etc. Said NO to upgrades as everything was carefully designed to provide the best possible machine design and performance. As we scoped and advertised. This is the truly ULTIMATE Bee. ULTIMATE Bee’ Frame Design Features. After many hours of research and prototyping and also getting feedback from the community, we worked on creating the ULTIMATE Bee. Has many features over previous CNC designs and our team has once again brought an innovating machine to. Some upgrades from the QueenBee PRO to the ULTIMATE Bee include. Ball Nut Bracket Gaskets. Precision laser cut 1.5mm rubber gaskets are used on all Ball Nut mounting. Brackets to allow for easy alignment while maintaining a ridged and secure join to the gantry plates. The Gasket aids in the building by compensating for any minor misalignment as well as acting to absorb vibrations during operation (essential in a more ridged drive system). Quiet Transmission Ball Screw Drive System. There are many benefits in using Ball Screws, such as high efficiency and r. High stiffness, high lead accuracy, and many other advantages. Compared with the contact thread lead screws. A Ball Screw adds balls between the nut and screw. The sliding friction of the conventional. Replaced by the rolling motion of the balls. The ULTIMATE Bee drive system has been upgraded to SFS1210 and. SFU1204 ball screws and ball nuts. 10mm pitch SFS1210 is used on all. Axis giving a noticeable increase in speed while maintaining the ability to be. Accurate and with measurable repeatability greater than or equal to 0.01mm. The calculated resolution of the Y, A and. X-axis of the ULTIMATE Bee is 0.00625mm at 1/8th micro-stepping. The Z-axis SFU1204 Ball Screws have a 4mm pitch so the Z calculated r. Esolution is 0.0025mm. Ball Screw Resolution vs Microstepping Table. SFU1204 – 4mm Pitch. SFS1210 – 10mm Pitch. By using an SFU1204 with 4mm pitch on the Z-Axis the system is able to maintain its position even while the motors are not energized. Even with heavier. 2.2kW water-cooled spindles! Choice means no more broken bits or spindles falling into stock when powering off. The 2040 Extrusion on the rear of the X-Axis has been replaced with a 4040 t. O allow for improved cable. By adding a 4040 extrusion to the back of a C-Beam Extrusion, the X-Axis is. Braced with a stronger support. All plates have been completely redesigned to incorporate better cable. Management, mounting sensors and. Switches, and allowing for more adaptive i. All of the main plates are made with thick 10mm aluminium. All surfaces where bearing carriages are mounted. Have been machined flat to provide a smooth. Surface for easy and accurate alignment. The Y and A Axis each utilise a single HGR15 linear rail with 2 x HGH15CA. Bearing carriages on the gantry. By using 2x HGR15 linear rails, one on. The Y and one on the A-side, instead of 4, this reduces the. Assembly and rail alignments without compromise on the performance. We have introduced diaphragm couplers with the ULTIMATE Bee machines. One of the main benefits of using. Diaphragm couplers instead of standard f. Lexible couplers is that there is significantly less backlash, as well as. Drastically increasing the resolution and repeatability of the system. Diaphragm couplers are also designed to have noise reduction and vibration c. Compensation increases the lifespan of the. Mechanical hardware used on the transmission system. What are Linear Rails and Bearings? Linear Rails consists of two parts, the rail and the bearing. The Rail is a precision machined strengthened. Steel assembly that has twin. Parallel tracks to guide a bearing (also know as roller) along. When combining the rail with the bearing you achieve low friction and high. Stiffness linear motion for loads. Ranging from 1kg to thousands of kilograms. Why use Linear Rails? There are many applications for using linear rails including industry. Medical, science, defence, mining. The benefit of linear rails over other types of linear guides are the rigidity. Accuracy and load capacity. Linear rails are designed to withstand force. Applied from loads in all directions, unlike other guides that are only design t. O withstand a load in one direction. Linear bearings use recirculating balls held in place under tensions for. The high strength construction of the bearings make them. Superior to previous wheel motion in respect to load capacity, displacement. Nema 23 Stepper Motor – High Torque. Holding torque: 2.45N. Rated voltage: 3.6V. Step angle: 1.8°±5%. Insulation resistane: 100M? Min. Insulation class: Class B. Resistance per phase: 1.2? ±10%. Inductance per phase: 4mH±20%. Suit for Controller: CNC xPROV5, UC300, High Current GRBL etc. “V-Slot” and ” C-Beam” are registered trademarks of OpenBuilds LLC as released under the Creative Commons Licence Attribution-Share.

USB 3/4Axis CNC 3040/6040/6090 CNC Router Engraver Milling Engraving Machine New. MODEL ONE:USB 4 Axis CNC 6090 Router 2200W. CNC 6090 router 4Axis+2.2kw Spindle motor +VFD +USB Port Metal Wood Engraver with. CNC Router engraving machine parameters. Outside dimension:1150x970x650mm(LxWxH). Working platform size:1045x720mm(LxW). Frame Material:The whole machine used 6061 aluminum profiles. Feeding height:? 140mm(From base of Z axis to platform). X, Y, Z Working Area:600x900x150mm. Sliding unit:X axis:SFU1605 Ball Screws;Y axis:SFU1605 Ball Screws;Z axis:SFU1204 Ball Screws. Drive unit:X axis:ø20 High intensity round rail, Y axis: SBRø20 high-strength aluminum base rails;Z axis: ø12 high-strength round rail. Stepping motor:two-phase 3A (with handwheels). Driving Power for Stepping motor:AC110,240W, Output DC24V10A. Maximum Idle speed:1500mm/m. Working Speed:50-1500mm/min (different material with different speed settings). Spindle motor:2200Whigh-speed variable frequency spindle motor, ER11 chuck, matching 6mm bur. Variable-frequency Drive(VFD):AC110V, 2200W, 0-400Hz(built-in Control box). Tips:1, The spindle motor must connect with the VFD. 2, It cannot directly connect with the supply voltage (AC110V/220V). 3, Please don’t change the data setting of the VFD if you are not professional technicians, or it might damage the spindle motor. Drive of Stepping motor. 0-3.5A adjustable four-axis driveTB6560AHQchip, 24V power supply, 2,4,8,16Subdivision. Settings, Factory setting:8subdivided. Repositioning precision:? 0.05mm. Cooling method:Water cooling, Matching heat dissipation water pump. Spindle precision:Radial runout? 0.03mm. Carving command:G code/TAB file/nc/TAB /NCC/file. Protection:Emergency stop button. Communication interface:through USB PORT connect with computer. Support system:Windows XP / win7 with 32bite. Gross weight of machine. Update function: with limit switch. Woodworking industry: sculpture, round carving, wooden handicraft processing. Advertising signs: logo making, cutting acrylic, plastic molding, suit for making a variety of materials advertising decorative products. Other industries: The engraver could do shadow-carved, sculpture which widely used in the gift industry; can be used in aluminum cutting industry, such as aluminum, aluminum-plastic plate, aluminum honeycomb panels, aluminum, 3D engraving process, Artificial plate, cutting LED and neon letter, making plastic light box model; also can engrave on acrylic, copper, PVC board, artificial stone, MDF board, and other metal sheet. 1, The NEW 2.2KW water-cooled VFD is available operating for long time, which can reinforced the processing ability of the machine and can be used to engrave on aluminum alloy and hard wood. 2, water cooling spindle works more stable and durable. 3, High quality accurate ball Screws drive make the engrving more precision. Anti-blackflash, high precision, long life circle. Assembling and locating the CNC machine on steady desk well. Make sure that your computer has a USB port output. Place the control box in a ventilated dry place where there is no dust, no moisture. Connecting the control box with the CNC machine and you computer and make sure the plug will not come off. Correctly connect the machine with the controller. Don’t suspended the cable which connect the Spindle motor with axis(X, Y, Z, A). Damage the driver of the controller. Correctly instal the Spindle motor and the heat pump. The heat pump should be covered completely in the water, then turned on the electric current to. Check whether the water-cooling system working well. Before turn on the machine, please check all the cable and water- cooling system to make sure they are working fine. You can enjoy making you dream with using our CNC machine now. 1X main unit (Frame). 1X main unit (working base). 1X Sinal cable for A axis. 10X 47mm round head. 6X 410mm black Inner six angle screw with nut. 8X 520mm black Inner six angle screw. 4X 58mm Flat Philip’s head screw with nut and gasket. 8X 624mm BALCK FLAT Inner six angle screw. 2X six angle Wrench(3mm). 2X six angle Wrench(4mm). 1x Tools Setting Auto-Check Instrument for CNC. MODEL TWO:USB 4 Axis CNC 6090 Router 1500W. 4Axis USB 1500W CNC Router Engraving Machine Engraver For Wood Acrylic 6090 Ball Screw. Model: CNC6090GZ Outside dimension: 1150970650mm(LWH) Working platform size: 1045720mm(LW) Frame Material:The whole machine used 6061 aluminum profiles Max. Feeding height:? 140mm(From base of Z axis to platform) X, Y, Z Working Area: 900(Y)600(X)140mm(Z). X axis:SFU1605 Ball Screws Y axis:SFU1605 Ball Screws Z axis:SFU1204 Ball Screws. X axis: ø20 High intensity round rail, Y axis: SBRø20 high-strength aluminum base rails Z axis: ø12 high-strength round rail Stepping motor: 57 two-phase 3A (with handwheels) Driving Power for Stepping motor: AC110, 240W, out put: DC24V, 10A Maximum Idle speed: 1500mm/min Working Speed: 50-1500mm / min (different material with different speed settings) Spindle motor: 1500W high-speed variable frequency spindle motor, ER11 chuck, with 6mm collet. The spindle motor must connect with the VFD. It cannot directly connect with the supply voltage (AC 110V). Please don’t change the data setting of the VFD if you are not professional technicians, or it might damage the spindle motor. Drive of Stepping motor: 0-3.5A adjustable four-axis drive (TB6560AHQ chip, 24V power supply, 2,4,8,16 subdivision can be set, factory settings 8 subdivision) Repositioning precision:? 0.05mm Cooling: Water-cooling Speed: 0-24000r/m Spindle precision: Radial runout? 0.03mm Carving command: G code / TAB file / nc file / NCC file VFD: AC110V, 1500W, 0-400Hz (built-in control box). USB Control box parameters. Protection: Emergency stop button Communication interface: through USB PORT connect with computer Support system: Windows XP / win7 with 32 bit. Input Volts: AC 110V. Woodworking industry: sculpture, round carving, wooden handicraft processing Advertising industry: advertising signs, logo making, cutting acrylic, plastic molding, suit for making a variety of materials advertising decorative products Other industries: The engraver could do shadow-carved, sculpture which widely used in the gift industry; can be used in aluminum cutting industry, such as aluminum, aluminum-plastic plate, aluminum honeycomb panels, aluminum, 3D engraving process, Artificial plate, cutting LED and neon letter, making plastic light box model; also can engrave on acrylic, copper, PVC board, artificial stone, MDF board, and other metal sheet. The NEW 1.5KW water-cooled VFD is available operating for long time, which can reinforced the processing ability of the machine and can be used to engrave on aluminum alloy and hard wood. Water cooling spindle works more stable and durable. High quality accurate ball Screws drive make the engrving more precision. Otherwise, it will damage the driver of the controller. The heat pump should be covered completely in the water, then turned on the electric current to check whether the water-cooling system working well. MODEL Three:USB 4 Axis CNC 6040 Router 1500W. 1X 25pin Parallel lines. Notes:Please prepare a computer with DB25 parallel Interface. Suitable for PCB, wood, Plexiglass, PVC, Crystal Acrylic, RESIN, Plastic, SEALS, MDF, COMPOSITE. Aluminum material, Copper, Iron. This CNC 6040T machine is suitable for industry, Technology Research, Advertising Design. Arts Creation, Teaching, Student Project and Hobby Purposes. It can work with various materials(metallic & non-metallic), such as: wood, pmma or other. Plastic, MDF board, native wood, PVC, Acrylic, wood, composite. Like aluminum, copper and silver to engrave them into. It can used for engraving: advertising signs, PCB, nameplates, badges, seals, bronzing plate, aluminum alloy, acrylic plates, ABS resin double color plate. PVC foaming board, indentation plates, signs, construction models, instrument panels, wooden products, etc. The mini CNC router Frame is movable. The machine can connect with computer as other. External device such as printer, scanner.. With the assist of the CNC ROUTER 6040T, your design idea will be real-time display. CNC Engraving Machine Parameters. X, Y, Z Working Area : 600(Y)390(X)120(Z)mm. Lathe structure : 6061/6063 Aluminum alloy. X axis :1605 Ball Screws. Y axis :1605 Ball Screws. Z axis:1204 Ball Screws. X axis:High intensity Chromeplate shaft. Y axis:High intensity Chromeplate shaft. Z axis:High intensity Chromeplate shaft. 1, The spindle motor must connect with the VFD. 2, It cannot directly connect with the supply voltage (AC110V). 3, Please don’t change the data setting of the VFD if you are not professional technicians. Or it might damage the spindle motor. Material:304 stainless steel, Copper coil, Pressure cast aluminum pipe water jacket. AC110V-220V/50Hz, 5A, 1.5KW VFD. Spindle speed : 24000 rpm. Max working frequency : 400Hz. Principal axis collet: ER11collet, Standard configuration :6mm. Speed mode:By adjusting the VFD output voltage and operating frequency. Lubrication way: lubricated by high grease. Repeat accuracy:0.05mm. Spindle precision:radial beat acuities 0.03mm. Carving Instructions: G code / TAB files / nc file / NCC files. Communication interface:through USB connection with computer. Support system: Windows XP WIN7. Maximum Idle speed:1500mm/min. Working Speed :50-1500mm / min (different material with different speed settings). Control unit:Toroidal transformer + PWM power supply module + TB6560 stepping motor drive. Command code:G code. 1, The NEW 1.5KW water-cooled VFD is available operating for long time, which can reinforced the processing abilty of the machine and can be used to. Process aluminum alloy and hard wood. Make sure that your computer has a 25pin parallel port output. Place the contral box in a ventilated dry place where there is no dust, no moisture. MODEL FOUR:USB 3 Axis CNC 6040 Router 1500W. 3 AXIS CNC Router 6040 Engraver Engraving Mill&Drill 3D. Suitable for PCB, wood, Plexi glass, PVC, Crystal Acrylic, RESIN, Plastic, SEALS, MDF, COMPOSITE, Aluminum material, Copper. This CNC 6040 machine is suitable for industry, Technology Research, Advertising Design, Arts Creation, Teaching, Student Project and Hobby Purposes. It can work with various materials(metallic & non-metallic), such as: wood, pmma or other plastic, MDF board, native wood, PVC, Acrylic, wood, composite board plywood. Like aluminum, copper and silver to engrave them into 3D/2D works etc. It can used for engraving: advertising signs, PCB, nameplates, badges, seals, bronzing plate, aluminum alloy, acrylic plates, ABS resin doublecolor plate, PVC foaming board, indentation plates, signs, construction models, instrument panels, wooden products, etc. The machine can connect with computer as other external device such as printer, scanner.. Cnc engraving machine parameters. X, Y, Z Working Area: 600(Y)390(X)120(Z)mm Outside dimension: 865680570mm(LWH) Table size: 770(Y)490(X)mm Lathe structure: 6061/6063 Aluminium alloy Max. It cannot directly connect with the supply voltage (AC220V). Outside dimension: 65158mm Material: 304 stainless steel, Copper coil, Pressure cast aluminum pipe water jacket VOLTS, current, power: AC110 /60Hz, 5A, 1.5KW VFD Spindle speed: 24000 rpm Max working frequency: 60Hz Principal axis collet: ER11collet, Standard configuration :6mm Nut Model: ER11-A Cooling: Water-cooling Speed mode: By adjusting the VFD output voltage and operating frequency from 0-24000RPM Lubrication way: lubricated by high grease Repeat accuracy: 0.05mm Spindle precision: radial beat acuities 0.03mm Carving Instructions: G code / TAB files / nc file / NCC files Communication interface: through USB connection with computer Support system: Windows XP/Win7. Operating Voltage: AC110V Control unit: Toroidal transformer + PWM power supply module + TB6560 stepping motor drive Computer connection: USB port Command code: G code. Protection: Emergency stop button. The NEW 1.5KW water-cooled VFD is available operating for long time, which can reinforced the processing abilty of the machine and can be used toprocess aluminum alloy and hard wood. Place the contral box in a ventilated dry place where there is no dust, no moisture 4. Otherwise, It will damage the driver of the controller. Before turn on the machine, please check all the cable and water-cooling system to make sure they are working fine. If you have any problem. MODEL Five:USB 4 Axis CNC 3040 Router 800W. 4Axis CNC Router 3040 Engraver Dril Milling Machine spindle motor VFD USB. CNC ROUTER ENGRAVING MACHINE ENGRAVER 3040 COOL SPINDLEMOTOR VFD 800W USB PORT. CNC ENGRAVING MACHINE parameters. X, Y, Z Working Area: 400(Y)295(X)80(Z)mm. Lathe structure: 6061/6063 Aluminium alloy. X axis—SFU01204-4 Ball Screws. Y axis—SFU01204-4 Ball Screws. Z axis—SFU01204-4 Ball Screws. X axis—High intensity Chromeplate shaft. Y axis—High intensity Chromeplate shaft. Z axis—High intensity Chromeplate shaft. It cannot directly connect with the supply voltage (220V). Material: 304 stainless steel, Copper coil, Pressure cast aluminum pipe water jacket. VOLTS, current, power: AC220V, 50Hz, 5A, 0.8KW VFD. Spindle speed: 24000 rpm. Max working frequency: 400Hz. Principal axis collet: ER11collet, Standard configuration:6mm. Speed mode: By adjusting the VFD output voltage and operating frequency from 0-24000RPM. Repeat accuracy: 0.05mm. Spindle precision: radial beat acuities 0.03mm. Communication interface: through USB connection with computer. Support system: windows XP / win7,32Bits. Carving speed: 0-2500mm/min(different materials differ). Control unit: Toroidal transformer + PWM power supply module + TB6560 stepping motor drive. Computer connection: USB port. Command code: G code. 8X 611mm BALCK FLAT Inner six angle screw. This CNC 3040T machine is suitable for industry, Technology Research, Advertising. Design, Arts Creation, Teaching, Student Project and Hobby Purposes. And soft metal, like aluminum, copper and silver to engrave them into 3D/2D works etc. It can used for engraving: advertising signs, PCB, nameplates, badges, seals, bronzing plate, aluminum. Alloy, acrylic plates, ABS resin double color plate, PVC foaming board, indentation plates, signs, construction models, instrument panels, wooden products, etc. With the assist of the CNC ROUTER 3040T, your design idea will be real-time display. The NEW 0.8KW water- cooled VFD is available operating for long time, which can reinforced the processing. Abilty of the machine and can be used to process aluminum alloy and hard wood. Anti- blackflash, high precision, long life circle. Connecting the control box with the CNC machine and you computer and make sure the plug will. Don’t suspended the cable which connect the. Spindle motor with axis(X, Y, Z, A). MODEL SIX:USB 4 Axis CNC 3040 Router 400W. 4 AXIS 3040 400W. More Precise Stepping Motor. The engraving process is visible as controlled by computer. Simple operation and installation. CNC 3040 is suitble for Industry, Technology Research, Advertising Design, Arts Creation, Teaching, Student Project and Hobby Purposes. CNC3040 is a desktop CNC machine and designd for processing Industrial or Hobby Prototype Building, Building Model Making, PCB. Adverstising Signs, Artwork, Crafts, Aircraft Models, RC Model parts, etc. So, you can do engraving work at office or home. Exquisite 3040 is a miniature version of mobile longmen structure of carving machine, put on you computer is like puting a printer or scanner that coordination, and can completely as a compute peripherals tools, anywhere, anytime, help you to design intent fast real appear. Nonmetal materials on the milling, and it can also be used to carving simple PCB/CNC. This 3040 engraer is a user-friendly desktop engraving machine for those with limited space and /or a limited budget. The Computerized CNC Engraving and Cutting Machine is suitable for various materials, such as WOOD, PMMA or other plastic. MDF board, native wood, PVC, Acrylic, wood, composite board plywood, It can be used widely to process or make adverstising signs, PCB. Nameplates, badges, seals, bronzing plate, aluminium alloy, acryplates, ABS resin double color plate, PVC foaming board, indentation plates, signs. Construction models, instrument panels, wooden products, etc. Effective working travel:275(X)mm385(Y)mm60(Z)mm. Work table dimension:320mm530mm. Frame materials:aluminum alloy 6063 and 6061. Leadscrew:1404 double thread Trapezoidal screws. Driving units:X axis:1204 trapezoidal screws. Y axis:1204 trapezoidal screws. Z axis:1204 trapezoidal screws. Sliding units:X axis:Dia. 16mm chrome plate shafts. 12mm chrome plate shafts. Stepping motor type:57 two-phase 1.8A. Spindle motor:400w dc motor 5008000PRM/Min. Principal axis collet:ER11 / 3.175 mm. Spindle precision:radial beat acuities 0.03 mm. Control unit:triaxial one-piece drive + ring variable power + PWM speed. Communication interface:USB PORT. Support system:windows XP / win7, 32Bits. Control unit:2.5A stepping motor driver plus adjustable spindle speed controller. Computer connection:USB port. Make sure that your computer has a on-board USB port output. Connecting the control box with the CNC machine and you computer. MODEL SEVEN:USB 4 Axis CNC 3020 Router 300W. 3020T 4AXIS CNC ROUTER ENGRAVER DRILL MILLING MACHINE 3D CUTTER ARTWORK. Item Units and Pictures (what you see what you get). CNC 3020 is suitble for Industry, Technology Research, Advertising Design, Arts Creation, Teaching, Student Project and Hobby Purposes. CNC 3020 is a desktop CNC machine and designd for processing Industrial or Hobby Prototype Building, Building Model Making, PCB, Adverstising Signs, Artwork, Crafts, Aircraft Models, RC Model parts, etc. So, you can do engraving work at office or home. Exquisite 3020 is a miniature version of mobile longmen structure of carving machine, put on you computer is like puting a printer or scanner that coordination, and can completely as a compute peripherals tools, anywhere, anytime, help you to design intent fast real appear. Engrave almost anything on almost any surface. X? Y? Z axis carving make more precise and and three-dimensional effect. Cover plates reducing pollution for the screws and shafts. More steady and strong equiped with aluminum alloy frame materials. Reinforced and thickened machine body make transportation absolutely to be safer and longerlife time. This 3020 engraer is a user-friendly desktop engraving machine for those with limited space and /or a limited budget. The Computerized CNC Engraving and Cutting Machine is suitable for various materials, such as WOOD, PMMA or other plastic, MDF board, native wood, PVC, Acrylic, wood, composite board plywood, It can be used widely to process or make adverstising signs, PCB, nameplates, badges, seals, bronzing plate, aluminium alloy, acryplates, ABS resin double color plate, PVC foaming board, indentation plates, signs, construction models, instrument panels, wooden products, etc. 3020T triaxial engraving machine part parameters. Effective working travel : 200(X)mm300(Y)mm45(Z)mm. Frame materials : aluminum alloy 6063 and 6061. X axis 1204 trapezoidal screws. Y axis 1204 trapezoidal screws. Z axis 1204 trapezoidal screws. 13mm chrome plate shafts. Stepping motor type : 57 two-phase 1.45A-2A. Spindle motor: 300w dc motor. Principal axis collet: ER11/3.175 mm. Spindle speed : 300 8000rpm/min (PWM stepless speed regulation). Empty line speed: 0-2500mm/min (16 subdivided driving down). Spindle precision: radial beat acuities 0.03 mm. Control unit: triaxial one-piece drive + ring variable power + PWM speed. Carving Instructions: G code/TAB files/nc file/NCC files. Communication interface through USB Port with computer. Support system : Windows 7/ xp. Carving speed: 0-2000mm/min (different materials differ). Control unit :2.5A stepping motor driver plus adjustable spindle speed controller. Command code G code. Protection Emergency :stop button. Can be controlled by computer. Can control the engraving more precise. Emergency stop button enhance security. Large 3D engraving in soft wood, MDF board, native wood, PVC, Acrylic we suggest use one or two spiral flute ball bits. Can engraving much more materails by spiral flute bits, such as metal, steel, MDF board, solid wood, composite board plywood, stone. Spindle motor knob is useful for small positioning adjustment, with steady and strong support structure. The reinforced and thickened machine body make transportation absolutely to be safer and longer life time. The chrome shafts is not easy to deform, suitable for long time use. Flexible coupling can be used for high torque transmission. High Precision Stepping motor makes engraving more precise. 32-bit version of Windows 2000, Windows XP, Windows Vista, or Windows 7 (64-bit versions will not work). Non-integrated Video Card with 32MB RAM(Large G-code files, especially 3D files will require a video card with 512MB RAM or higher). MODEL Eight:USB 3 Axis CNC 3040 Router 400W. USB CNC ROUTER 3 axis 3040 400W ENGRAVER/ENGRAVING MILLING M/C 110AV. Reinforced and thickened machine body make transportation absolutely to be safer and longer life time. CNC3040 is suitble for Industry, Technology Research, Advertising Design, Arts Creation. Teaching, Student Project and Hobby Purposes. CNC3040 is a desktop CNC machine and designd for processing Industrial or Hobby. Prototype Building, Building Model Making, PCB. Adverstising Signs, Artwork, Crafts, Aircraft Models, RC Model parts, etc. So, you can do. Engraving work at office or home. Exquisite 3040 is a miniature version of mobile longmen structure of carving machine. Put on you computer is like puting a printer or scanner that coordination, and can. Completely as a compute peripherals tools, anywhere, anytime, help you to design intent fast real appear. This 3040 engraer is a user-friendly desktop engraving machine for those with limited space. And /or a limited budget. The Computerized CNC Engraving and Cutting Machine is suitable for various materials. Such as WOOD, PMMA or other plastic. MDF board, native wood, PVC, Acrylic, wood, composite board plywood, It can be used. Widely to process or make adverstising signs, PCB. Nameplates, badges, seals, bronzing plate, aluminium alloy, acryplates, ABS resin double. Color plate, PVC foaming board, indentation plates, signs. 3040T triaxial engraving machine part parameters. Effective working travel :275(X)mm385(Y)mm70(Z)mm. Work table dimension :320mm530mm. Frame materials :aluminum alloy 6063 and 6061. Leadscrew :1404 double thread Trapezoidal screws. X axis:1404 trapezoidal screws. Y axis:1404 trapezoidal screws. Z axis:1404 trapezoidal screws. Stepping motor type :57 two-phase 1.8A. Spindle motor :400w dc motor 5008000PRM/Min. Principal axis collet :ER11 / 3.175 mm. Repeat accuracy :0.05mm. Spindle precision :radial beat acuities 0.03 mm. Control unit :triaxial one-piece drive + ring variable power + PWM speed. Communication interface :through USB Port with computer. Support system :windows XP / win7. Operating Voltage: AC110V US PLUG. Control unit: 2.5A stepping motor driver plus adjustable spindle speed controller. Computer connection: on board palrallel port. Installment Support system is simple and intellgent. Feedback is very important to us. It is impossible to address issues if we do not know about them! Faction is our ultimate goal. We work hard to earn your trust and future business. A If you receive a defective item, you may return it or ask for a discount. Due to time zones, our reply to your questions may not be immediately. If it’s non-workdays, please kindly be patient and wait till Monday. Creative Design, Durable Material, Beautiful Appearance. Easy installation, Convenient Use, Easy Operation.

1500W 3/4 Axis 6040 CNC Router Desktop Engraver Metalworking Milling Machine. 4 AXIS 1500W USB PORT. This CNC 6040T machine is suitable for industry, Technology Research, Advertising Design, Arts Creation, Teaching, Student Project and Hobby Purposes. It can work with various materials(metallic & non-metallic), such as: wood, pmma or other plastic, MDF board, native wood, PVC, Acrylic, wood, composite board plywood. And soft metal, like aluminum, copper and silver to engrave them into 3D/2D works etc. It can used for engraving: advertising signs, PCB, nameplates, badges, seals, bronzing plate, aluminum alloy, acrylic plates, ABS resin double color plate, PVC foaming board, indentation plates, signs, construction models. Instrument panels, wooden products, etc. The mini CNC router Frame is movable. The machine can connect with computer as other external device such as printer, scanner.. With the assist of the CNC ROUTER 6040T, your design idea will be real-time display. CNC engraving machine parameters. X, Y, Z Working Area: 600(Y)390. Lathe structure: 6061/6063 Aluminium alloy. Y axis—1605 Ball Screws. Z axis—1204 Ball Screws. X axis—High intensity Chromeplate shaft. Y axis—High intensity Chromeplate shaft. Z axis—High intensity Chromeplate shaft. The spindle motor must connect with the VFD. It cannot directly connect with the supply voltage (AC 220V). Please don’t change the data setting of the VFD if you are not professional technicians, or it might damage the spindle motor. Material: 304 stainless steel, Copper coil, Pressure cast aluminum pipe water jacket. VOLTS, current, power: AC 220V, 50Hz, 5A. 1.5 KW VFD. Spindle speed: 24000 rpm. Max working frequency: 400Hz. Principal axis collet: ER11collet, Standard configuration :6mm. Speed mode: By adjusting the VFD output voltage and operating frequency from 0-24000RPM. Lubrication way: lubricated by high grease. Repeat accuracy: 0.05mm. Spindle precision: radial beat acuities 0.03mm. Carving Instructions: G code / TAB files / nc file / NCC files. Communication interface: through USB connection with computer. Support system: windows XP / win7 32bits system. Carving speed: 0-2500mm/min(different materials differ). Operating Voltage: AC 220V. Control unit: Toroidal transformer + PWM power supply module + TB6560 stepping motor drive. Command code: G code. Protection: Emergency stop button. 1.5KW water-cooled VFD. Is available operating for long time, which can reinforced the processing ability of the machine and can be used to process aluminum alloy and hard wood. Water cooling spindle works more stable and durable. High quality accurate ball Screws drive make the engraving more precision. Anti-blackflash, high precision, long life circle. Assembling and locating the CNC machine on steady desk well. Make sure that your computer has a USB port output. Place the control box in a ventilated dry place where there is no dust, no moisture. Connecting the control box with the CNC machine and you computer and make sure the plug will not come off. Correctly connect the machine with the controller. Don’t suspended the cable which connect the Spindle motor with axis(X, Y, Z, A). It will damage the driver of the controller. Correctly install the Spindle motor and the heat pump. The heat pump should be covered completely in the water, then turned on the electric current to check whether the water-cooling system working well. Before turn on the machine, please check all the cable and water- cooling system to make sure they are working fine. You can enjoy making you dream with using our CNC machine now. 4 AXIS 1500W USB PORT+RC. Notes:Please prepare a computer with USB Interface. 1X main unit (Frame). 1X main unit (working base). 1X Sinal cable for A axis. 1X 25pin Parallel lines. 10X 47mm round head. 6X 410mm black Inner six angle screw with nut. 8X 520mm black Inner six angle screw. 4X 58mm Flat Philip’s head screw with nut and gasket. 8X 624mm BALCK FLAT Inner six angle screw. 2X six angle Wrench(3mm). 2X six angle Wrench(4mm). Suitable for PCB, wood, Plexiglass, PVC, Crystal Acrylic, RESIN, Plastic, SEALS, MDF, COMPOSITE, Aluminum material, Copper, Iron. It can work with various materials(metallic & non-metallic), such as: wood, pmma or other. Plastic, MDF board, native wood, PVC, Acrylic, wood, composite. Like aluminum, copper and silver to engrave them into. It can used for engraving: advertising signs, PCB, nameplates, badges, seals, bronzing plate, aluminum alloy, acrylic plates, ABS resin double color plate, PVC foaming board, indentation plates, signs, construction models, instrument panels, wooden products, etc. The machine can connect with computer as other. External device such as printer, scanner.. CNC Engraving Machine Parameters. X, Y, Z Working Area : 600(Y)390. Lathe structure : 6061/6063 Aluminum alloy. Y axis :1605 Ball Screws. Z axis:1204 Ball Screws. High intensity Chromeplate shaft. 1, The spindle motor must connect with the VFD. 2, It cannot directly connect with the supply voltage (AC110V). 3, Please don’t change the data setting of the VFD if you are not professional technicians, or it might damage the spindle motor. Pressure cast aluminum pipe water jacket. 5A, 1.5KW VFD. Spindle speed : 24000 rpm. Max working frequency : 400Hz. Principal axis collet: ER11collet. Speed mode:By adjusting the VFD output voltage and operating frequency. Repeat accuracy:0.05mm. Spindle precision:radial beat acuities 0.03mm. Communication interface:through USB connection with computer. Maximum Idle speed:1500mm/min. Working Speed :50-1500mm / min (different material with different speed settings). Control unit:Toroidal transformer + PWM power supply module + TB6560 stepping motor drive. Computer connection:USB port. Command code:G code. Protection:Emergency stop button. 1, The NEW 1.5KW water-cooled VFD is available operating for long time, which can reinforced the processing abil. Ty of the machine and can be used to. Process aluminum alloy and hard wood. 2, water cooling spindle works more stable and durable. 3, High quality accurate ball Screws drive make the engrving more precision. Make sure that your computer has a 25pin parallel port output. L box in a ventilated dry place where there is no dust, no moisture. Damage the driver of the controller. L the Spindle motor and the heat pump. The heat pump should be covered completely in the water, then turned on the electric current to. Check whether the water-cooling system working well. Waterproof design, very durable, anti-dirt, oil spray. Power by USB port. Dimensions: 22 x 8 x 3cm. The usb self-check light, you can type the ” scroll” on the keyboard to activate it. Directional motion control: X+, X-, Y+, Y-, Z+, Z-, A+, A. Feed rate control: F+, F. Jog rate: J+, J. Spindle speed: speed up, slow down. Programming: E-stop, cycle start, spindle on/off, Redo, single step, original point. 3 AXIS 1500W USB PORT. Suitable for PCB, wood, Plexi glass, PVC, Crystal Acrylic, RESIN, Plastic, SEALS, MDF, COMPOSITE, Aluminum material, Copper. This CNC 6040 machine is suitable for industry, Technology Research, Advertising Design, Arts Creation, Teaching, Student Project and Hobby Purposes. Like aluminum, copper and silver to engrave them into 3D/2D works etc. It can used for engraving: advertising signs, PCB, nameplates, badges, seals, bronzing plate, aluminum alloy, acrylic plates, ABS resin doublecolor plate, PVC foaming board, indentation plates, signs, construction models, instrument panels, wooden products, etc. Cnc engraving machine parameters. It cannot directly connect with the supply voltage (AC220V). VOLTS, current, power: AC110 /60Hz, 5A, 1.5KW VFD. Max working frequency: 60Hz. Support system: Windows XP/Win7. Computer connection: USB port. The NEW 1.5KW water-cooled VFD is available operating for long time, which can reinforced the processing abilty of the machine and can be used toprocess aluminum alloy and hard wood. High quality accurate ball Screws drive make the engrving more precision. Otherwise, It will damage the driver of the controller. The Spindle motor and the heat pump. Before turn on the machine, please check all the cable and water-cooling system to make sure they are working fine. (3 AXIS 1500W USB PORT+RC). Mode: By adjusting the VFD output voltage and operating frequency from 0-24000RPM. Is available operating for long time, which can reinforced the processing abil. High quality accurate ball Screws drive make the engr. Flash, high precision, long life circle. (3 AXIS 1500W Parallel Port). Notes:Please prepare a computer with DB25 parallel Interface. This machine needs to connect to a computer through its controller box with a. Parallel cable (both included). It is not recommended to connect to a notebook through a. Parallel port as the power saving features tend to interrupt the data flow. It is also not recommended to connect to a computers with 64 bit versions of Windows due to problems with the Parallel port driver. Suitable for PCB, wood, Plexiglass, PVC, Crystal Acrylic, RESIN, Plastic, SEALS, MDF, COMPOSITE, Aluminum material, Copper. Lathe structure:6061/6063 Aluminium alloy. Y axis:1204 Ball Screws. X axis:High intensity Chromeplate shaft. Y axis:High intensity Chromeplate shaft. Z axis:High intensity Chromeplate shaft. Material:304 stainless steel. Spindle speed:24000 rpm. Max working frequency:400Hz. Principal axis collet:ER11collet. Mode:By adjusting the VFD output voltage and operating frequency from 0-24000RPM. Lubrication way:lubricated by high grease. Carving Instructions:G code / TAB files / nc file / NCC files. Communication interface:through parallel connection with computer. Support system:windows XP / win7. Toroidal transformer + PWM power supply module + TB6560 stepping motor drive. 3, High quality accurate ball Screws drive make the engr. Connecting the control box with the CNC machine and you computer. And make sure the plug will not come off. (3 AXIS 1500W Parallel Port+RC). Notes: Please prepare a computer with DB25 parallel Interface. PCB, wood, Plexiglass, PVC, Crystal Acrylic, RESIN, Plastic, SEALS, MDF, COMPOSITE, Aluminum material, Copper. This 6040T machine is suitable for industry, Technology Research, Advertising Design, Arts Creation, Teaching, Student Project and Hobby Purposes. The mini router Frame is movable. With the assist of the ROUTER 6040T, your design idea will be real-time display. Y axis–1605 Ball Screws. Z axis–1204 Ball Screws. X axis–High intensity Chromeplate shaft. Y axis–High intensity Chromeplate shaft. Z axis–High intensity Chromeplate shaft. It cannot directly connect with the supply voltage (AC110V). VOLTS, current, power: AC110 /60Hz, 5A. Principal axis collet: ER11collet, Standard configuration: 6mm. Communication interface: through parallel connection with computer. Environment: Windows XP / Win7, 32bits system. Computer connection: Parallel port. 1.5 KW water-cooled VFD. Ty of the machine and can be used to process aluminum alloy and hard wood. Compatability: fit for Type3/ArtCAMParameter. Assembling and locating the machine on steady desk well. Connecting the control box with the machine and you computer and make sure the plug will not come off. Installing a control Drive on your computer. Llowing our manual or guideline to set. You can enjoy making you dream with using our machine now. (5 AXIS 1500W USB Port). Make sure that your computer has a 25pin USB port output. Don’t suspended the cable which connect the Spindle motor with axis(X, Y, Z, A, B). Highlights of water cooling system. It can cool the spindle and protect the machine. Avoid the spindle burn out. Can engrave the high hardness or metal. It can improve the efficiency and accuracy of the machine. 2X Sinal cable for A B axis. This 6040T machine is suitable for industry, Technology Research. Advertising Design, Arts Creation, Teaching, Student Project and Hobby Purposes. With the assist of the ROUTER 6040, your design idea will be real-time display. X, Y, Z Working Area:600(Y)390. Y axis:1605 Ball Screws. Material:304 stainless steel, Copper coil, Pressure cast aluminum pipe water jacket. Speed mode:By adjusting the VFD output voltage and operating frequency:from 0-24000RPM. Software environment:32-bit version of Windows 2000, Windows XP, Windows Vista, or Windows 7 (64-bit versions will not work). Non-integrated Video Card with 32MB RAM(Large G-code files, especially 3D files will require a video card with 512MB RAM or higher). 50-1500mm/min(different material with different speed settings). Anti-black flash, high precision, long life circle. Note:We only sell machine without software. Feedback is very important to us. It is impossible to address issues if we do not know about them! Faction is our ultimate goal. We work hard to earn your trust and future business. A If you receive a defective item, you may return it or ask for a discount. Due to time zones, our reply to your questions may not be immediately. If it’s non-workdays, please kindly be patient and wait till Monday.

USB 3/4Axis CNC 3040/6040/6090 Router Engraver Engraving Machine 300W-2200W USA. Note:We only sell machine without software. MODEL ONE:USB 4 Axis CNC 6090 Router 2200W. CNC 6090 router 4Axis+2.2kw Spindle motor +VFD +USB Port Metal Wood Engraver with. CNC Router engraving machine parameters. Outside dimension:1150x970x650mm(LxWxH). Working platform size:1045x720mm(LxW). Frame Material:The whole machine used 6061 aluminum profiles. Feeding height:? 140mm(From base of Z axis to platform). X, Y, Z Working Area:600x900x150mm. Sliding unit:X axis:SFU1605 Ball Screws;Y axis:SFU1605 Ball Screws;Z axis:SFU1204 Ball Screws. Drive unit:X axis:ø20 High intensity round rail, Y axis: SBRø20 high-strength aluminum base rails;Z axis: ø12 high-strength round rail. Stepping motor:two-phase 3A. Driving Power for Stepping motor:AC110,240W, Output DC24V10A. Maximum Idle speed:1500mm/m. Working Speed:50-1500mm/min (different material with different speed settings). Spindle motor:2200Whigh-speed variable frequency spindle motor, ER11 chuck, matching 6mm bur. Variable-frequency Drive(VFD):AC110V, 2200W, 0-400Hz(built-in Control box). Tips1, The spindle motor must connect with the VFD. 2, It cannot directly connect with the supply voltage (AC110V/220V). 3, Please don’t change the data setting of the VFD if you are not professional technicians, or it might damage the spindle motor. Drive of Stepping motor. 0-3.5A adjustable four-axis driveTB6560AHQchip, 24V power supply, 2,4,8,16Subdivision. Settings, Factory setting:8subdivided. Repositioning precision:? 0.05mm. Cooling method:Water cooling, Matching heat dissipation water pump. Spindle precision:Radial runout? 0.03mm. Carving command:G code/TAB file/nc/TAB /NCC/file. Protection:Emergency stop button. Communication interface:through USB PORT connect with computer. Support system:Windows XP / win7 with 32bite. Gross weight of machine. Update function: with limit switch. Woodworking industry: sculpture, round carving, wooden handicraft processing. Advertising signs: logo making, cutting acrylic, plastic molding, suit for making a variety of materials advertising decorative products. Other industries: The engraver could do shadow-carved, sculpture which widely used in the gift industry; can be used in aluminum cutting industry, such as aluminum, aluminum-plastic plate, aluminum honeycomb panels, aluminum, 3D engraving process, Artificial plate, cutting LED and neon letter, making plastic light box model; also can engrave on acrylic, copper, PVC board, artificial stone, MDF board, and other metal sheet. 1, The NEW 2.2KW water-cooled VFD is available operating for long time, which can reinforced the processing ability of the machine and can be used to engrave on aluminum alloy and hard wood. 2, water cooling spindle works more stable and durable. 3, High quality accurate ball Screws drive make the engrving more precision. Anti-blackflash, high precision, long life circle. Assembling and locating the CNC machine on steady desk well. Make sure that your computer has a USB port output. Place the control box in a ventilated dry place where there is no dust, no moisture. Connecting the control box with the CNC machine and you computer and make sure the plug will not come off. Correctly connect the machine with the controller. Don’t suspended the cable which connect the Spindle motor with axis(X, Y, Z, A). Damage the driver of the controller. Correctly instal the Spindle motor and the heat pump. The heat pump should be covered completely in the water, then turned on the electric current to. Check whether the water-cooling system working well. Before turn on the machine, please check all the cable and water- cooling system to make sure they are working fine. You can enjoy making you dream with using our CNC machine now. 1X main unit (Frame). 1X main unit (working base). 1X Sinal cable for A axis. 10X 47mm round head. 6X 410mm black Inner six angle screw with nut. 8X 520mm black Inner six angle screw. 4X 58mm Flat Philip’s head screw with nut and gasket. 8X 624mm BALCK FLAT Inner six angle screw. 2X six angle Wrench(3mm). 2X six angle Wrench(4mm). 1x Tools Setting Auto-Check Instrument for CNC. MODEL TWO:USB 4 Axis CNC 6090 Router 1500W. 4Axis USB 1500W CNC Router Engraving Machine Engraver For Wood Acrylic 6090 Ball Screw. Model: CNC6090GZ Outside dimension: 1150970650mm(LWH) Working platform size: 1045720mm(LW) Frame MaterialThe whole machine used 6061 aluminum profiles Max. Feeding height:? 140mm(From base of Z axis to platform) X, Y, Z Working Area: 900(Y)600(X)140mm(Z). X axis:SFU1605 Ball Screws Y axis:SFU1605 Ball Screws Z axis:SFU1204 Ball Screws. X axis: ø20 High intensity round rail, Y axis: SBRø20 high-strength aluminum base rails Z axis: ø12 high-strength round rail Stepping motor: 57 two-phase 3A Driving Power for Stepping motor: AC110, 240W, out put: DC24V, 10A Maximum Idle speed: 1500mm/min Working Speed: 50-1500mm / min (different material with different speed settings) Spindle motor: 1500W high-speed variable frequency spindle motor, ER11 chuck, with 6mm collet. The spindle motor must connect with the VFD. It cannot directly connect with the supply voltage (AC 110V). Please don’t change the data setting of the VFD if you are not professional technicians, or it might damage the spindle motor. Drive of Stepping motor: 0-3.5A adjustable four-axis drive (TB6560AHQ chip, 24V power supply, 2,4,8,16 subdivision can be set, factory settings 8 subdivision) Repositioning precision:? 0.05mm Cooling: Water-cooling Speed: 0-24000r/m Spindle precision: Radial runout? 0.03mm Carving command: G code / TAB file / nc file / NCC file VFD: AC110V, 1500W, 0-400Hz (built-in control box). USB Control box parameters. Protection: Emergency stop button Communication interface: through USB PORT connect with computer Support system: Windows XP / win7 with 32 bit. Input Volts: AC 110V. Woodworking industry: sculpture, round carving, wooden handicraft processing Advertising industry: advertising signs, logo making, cutting acrylic, plastic molding, suit for making a variety of materials advertising decorative products Other industries: The engraver could do shadow-carved, sculpture which widely used in the gift industry; can be used in aluminum cutting industry, such as aluminum, aluminum-plastic plate, aluminum honeycomb panels, aluminum, 3D engraving process, Artificial plate, cutting LED and neon letter, making plastic light box model; also can engrave on acrylic, copper, PVC board, artificial stone, MDF board, and other metal sheet. The NEW 1.5KW water-cooled VFD is available operating for long time, which can reinforced the processing ability of the machine and can be used to engrave on aluminum alloy and hard wood. Water cooling spindle works more stable and durable. High quality accurate ball Screws drive make the engrving more precision. Otherwise, it will damage the driver of the controller. The heat pump should be covered completely in the water, then turned on the electric current to check whether the water-cooling system working well. MODEL Three:USB 4 Axis CNC 6040 Router 1500W. 1X 25pin Parallel lines. Notes:Please prepare a computer with DB25 parallel Interface. Suitable for PCB, wood, Plexiglass, PVC, Crystal Acrylic, RESIN, Plastic, SEALS, MDF, COMPOSITE. Aluminum material, Copper, Iron. This CNC 6040T machine is suitable for industry, Technology Research, Advertising Design. Arts Creation, Teaching, Student Project and Hobby Purposes. It can work with various materials(metallic & non-metallic), such as: wood, pmma or other. Plastic, MDF board, native wood, PVC, Acrylic, wood, composite. Like aluminum, copper and silver to engrave them into. It can used for engraving: advertising signs, PCB, nameplates, badges, seals, bronzing plate, aluminum alloy, acrylic plates, ABS resin double color plate. PVC foaming board, indentation plates, signs, construction models, instrument panels, wooden products, etc. The mini CNC router Frame is movable. The machine can connect with computer as other. External device such as printer, scanner.. With the assist of the CNC ROUTER 6040T, your design idea will be real-time display. CNC Engraving Machine Parameters. X, Y, Z Working Area : 600(Y)390X120(Z)mm. Lathe structure : 6061/6063 Aluminum alloy. X axis :1605 Ball Screws. Y axis :1605 Ball Screws. Z axis:1204 Ball Screws. X axisHigh intensity Chromeplate shaft. Y axisHigh intensity Chromeplate shaft. Z axisHigh intensity Chromeplate shaft. 1, The spindle motor must connect with the VFD. 2, It cannot directly connect with the supply voltage (AC110V). 3, Please don’t change the data setting of the VFD if you are not professional technicians. Or it might damage the spindle motor. Material304 stainless steelCopper coilPressure cast aluminum pipe water jacket. AC110V-220V/50Hz5A, 1.5KW VFD. Spindle speed : 24000 rpm. Max working frequency : 400Hz. Principal axis collet: ER11colletStandard configuration :6mm. Speed mode:By adjusting the VFD output voltage and operating frequency. Lubrication way: lubricated by high grease. Repeat accuracy:0.05mm. Spindle precision:radial beat acuities 0.03mm. Carving Instructions: G code / TAB files / nc file / NCC files. Communication interface:through USB connection with computer. Support system: Windows XP WIN7. Maximum Idle speed:1500mm/min. Working Speed :50-1500mm / min (different material with different speed settings). Control unit:Toroidal transformer + PWM power supply module + TB6560 stepping motor drive. Command code:G code. 1, The NEW 1.5KW water-cooled VFD is available operating for long time, which can reinforced the processing abilty of the machine and can be used to. Process aluminum alloy and hard wood. Make sure that your computer has a 25pin parallel port output. Place the contral box in a ventilated dry place where there is no dust, no moisture. MODEL FOUR:USB 3 Axis CNC 6040 Router 1500W. 3 AXIS CNC Router 6040 Engraver Engraving Mill&Drill 3D. Suitable for PCB, wood, Plexi glass, PVC, Crystal Acrylic, RESIN, Plastic, SEALS, MDF, COMPOSITE, Aluminum material, Copper. This CNC 6040 machine is suitable for industry, Technology Research, Advertising Design, Arts Creation, Teaching, Student Project and Hobby Purposes. It can work with various materials(metallic & non-metallic), such as: wood, pmma or other plastic, MDF board, native wood, PVC, Acrylic, wood, composite board plywood. Like aluminum, copper and silver to engrave them into 3D/2D works etc. It can used for engraving: advertising signs, PCB, nameplates, badges, seals, bronzing plate, aluminum alloy, acrylic plates, ABS resin doublecolor plate, PVC foaming board, indentation plates, signs, construction models, instrument panels, wooden products, etc. The machine can connect with computer as other external device such as printer, scanner.. Cnc engraving machine parameters. X, Y, Z Working Area: 600(Y)390X120(Z)mm Outside dimension: 865680570mmLWH Table size: 770Y490Xmm Lathe structure: 6061/6063 Aluminium alloy Max. It cannot directly connect with the supply voltage (AC220V). Outside dimension: 65158mm Material: 304 stainless steel, Copper coil, Pressure cast aluminum pipe water jacket VOLTS, current, power: AC110 /60Hz, 5A, 1.5KW VFD Spindle speed: 24000 rpm Max working frequency: 60Hz Principal axis collet: ER11colletStandard configuration :6mm Nut Model: ER11-A Cooling: Water-cooling Speed mode: By adjusting the VFD output voltage and operating frequency from 0-24000RPM Lubrication way: lubricated by high grease Repeat accuracy: 0.05mm Spindle precision: radial beat acuities 0.03mm Carving Instructions: G code / TAB files / nc file / NCC files Communication interface: through USB connection with computer Support system: Windows XP/Win7. Operating Voltage: AC110V Control unit: Toroidal transformer + PWM power supply module + TB6560 stepping motor drive Computer connection: USB port Command code: G code. Protection: Emergency stop button. The NEW 1.5KW water-cooled VFD is available operating for long time, which can reinforced the processing abilty of the machine and can be used toprocess aluminum alloy and hard wood. Place the contral box in a ventilated dry place where there is no dust, no moisture 4. Otherwise, It will damage the driver of the controller. Before turn on the machine, please check all the cable and water-cooling system to make sure they are working fine. If you have any problem. MODEL Five:USB 4 Axis CNC 3040 Router 800W. 4Axis CNC Router 3040 Engraver Dril Milling Machine spindle motor VFD USB. CNC ROUTER ENGRAVING MACHINE ENGRAVER 3040 COOL SPINDLEMOTOR VFD 800W USB PORT. CNC ENGRAVING MACHINE parameters. X, Y, Z Working Area: 400(Y)295X80(Z)mm. Lathe structure: 6061/6063 Aluminium alloy. X axis—SFU01204-4 Ball Screws. Y axis—SFU01204-4 Ball Screws. Z axis—SFU01204-4 Ball Screws. X axis—High intensity Chromeplate shaft. Y axis—High intensity Chromeplate shaft. Z axis—High intensity Chromeplate shaft. It cannot directly connect with the supply voltage (220V). Material: 304 stainless steel, Copper coil, Pressure cast aluminum pipe water jacket. VOLTS, current, power: AC220V, 50Hz, 5A, 0.8KW VFD. Spindle speed: 24000 rpm. Max working frequency: 400Hz. Principal axis collet: ER11collet, Standard configuration:6mm. Speed mode: By adjusting the VFD output voltage and operating frequency from 0-24000RPM. Repeat accuracy: 0.05mm. Spindle precision: radial beat acuities 0.03mm. Communication interface: through USB connection with computer. Support system: windows XP / win7,32Bits. Carving speed: 0-2500mm/mindifferent materials differ. Control unit: Toroidal transformer + PWM power supply module + TB6560 stepping motor drive. Computer connection: USB port. Command code: G code. 8X 611mm BALCK FLAT Inner six angle screw. This CNC 3040T machine is suitable for industry, Technology Research, Advertising. Design, Arts Creation, Teaching, Student Project and Hobby Purposes. And soft metal, like aluminum, copper and silver to engrave them into 3D/2D works etc. It can used for engraving: advertising signs, PCB, nameplates, badges, seals, bronzing plate, aluminum. Alloy, acrylic plates, ABS resin double color plate, PVC foaming board, indentation plates, signs, construction models, instrument panels, wooden products, etc. With the assist of the CNC ROUTER 3040T, your design idea will be real-time display. The NEW 0.8KW water- cooled VFD is available operating for long time, which can reinforced the processing. Abilty of the machine and can be used to process aluminum alloy and hard wood. Anti- blackflash, high precision, long life circle. Connecting the control box with the CNC machine and you computer and make sure the plug will. Don’t suspended the cable which connect the. Spindle motor with axis(X, Y, Z, A). MODEL SIX:USB 4 Axis CNC 3040 Router 400W. 4 AXIS 3040 400W. More Precise Stepping Motor. The engraving process is visible as controlled by computer. Simple operation and installation. CNC 3040 is suitble for Industry, Technology Research, Advertising Design, Arts Creation, Teaching, Student Project and Hobby Purposes. CNC3040 is a desktop CNC machine and designd for processing Industrial or Hobby Prototype Building, Building Model Making, PCB. Adverstising Signs, Artwork, Crafts, Aircraft Models, RC Model parts, etc. So, you can do engraving work at office or home. Exquisite 3040 is a miniature version of mobile longmen structure of carving machine, put on you computer is like puting a printer or scanner that coordination, and can completely as a compute peripherals tools, anywhere, anytime, help you to design intent fast real appear. Nonmetal materials on the milling, and it can also be used to carving simple PCB/CNC. This 3040 engraer is a user-friendly desktop engraving machine for those with limited space and /or a limited budget. The Computerized CNC Engraving and Cutting Machine is suitable for various materials, such as WOOD, PMMA or other plastic. MDF board, native wood, PVC, Acrylic, wood, composite board plywood, It can be used widely to process or make adverstising signs, PCB. Nameplates, badges, seals, bronzing plate, aluminium alloy, acryplates, ABS resin double color plate, PVC foaming board, indentation plates, signs. Construction models, instrument panels, wooden products, etc. Effective working travel:275(X)mm385(Y)mm60(Z)mm. Work table dimension:320mm530mm. Frame materials:aluminum alloy 6063 and 6061. Leadscrew:1404 double thread Trapezoidal screws. Driving units:X axis:1204 trapezoidal screws. Y axis:1204 trapezoidal screws. Z axis:1204 trapezoidal screws. Sliding units:X axis:Dia. 16mm chrome plate shafts. 12mm chrome plate shafts. Stepping motor type:57 two-phase 1.8A. Spindle motor:400w dc motor 5008000PRM/Min. Principal axis collet:ER11 / 3.175 mm. Spindle precision:radial beat acuities 0.03 mm. Control unit:triaxial one-piece drive + ring variable power + PWM speed. Communication interface:USB PORT. Support system:windows XP / win7, 32Bits. Control unit:2.5A stepping motor driver plus adjustable spindle speed controller. Computer connection:USB port. Make sure that your computer has a on-board USB port output. Connecting the control box with the CNC machine and you computer. MODEL SEVEN:USB 4 Axis CNC 3020 Router 300W. 3020T 4AXIS CNC ROUTER ENGRAVER DRILL MILLING MACHINE 3D CUTTER ARTWORK. Item Units and Pictures (what you see what you get). CNC 3020 is suitble for Industry, Technology Research, Advertising Design, Arts Creation, Teaching, Student Project and Hobby Purposes. CNC 3020 is a desktop CNC machine and designd for processing Industrial or Hobby Prototype Building, Building Model Making, PCB, Adverstising Signs, Artwork, Crafts, Aircraft Models, RC Model parts, etc. So, you can do engraving work at office or home. Exquisite 3020 is a miniature version of mobile longmen structure of carving machine, put on you computer is like puting a printer or scanner that coordination, and can completely as a compute peripherals tools, anywhere, anytime, help you to design intent fast real appear. Engrave almost anything on almost any surface. XYZ axis carving make more precise and and three-dimensional effect. Cover plates reducing pollution for the screws and shafts. More steady and strong equiped with aluminum alloy frame materials. Reinforced and thickened machine body make transportation absolutely to be safer and longerlife time. This 3020 engraer is a user-friendly desktop engraving machine for those with limited space and /or a limited budget. The Computerized CNC Engraving and Cutting Machine is suitable for various materials, such as WOOD, PMMA or other plastic, MDF board, native wood, PVC, Acrylic, wood, composite board plywood, It can be used widely to process or make adverstising signs, PCB, nameplates, badges, seals, bronzing plate, aluminium alloy, acryplates, ABS resin double color plate, PVC foaming board, indentation plates, signs, construction models, instrument panels, wooden products, etc. 3020T triaxial engraving machine part parameters. Effective working travel : 200(X)mm300(Y)mm45(Z)mm. Frame materials : aluminum alloy 6063 and 6061. X axis 1204 trapezoidal screws. Y axis 1204 trapezoidal screws. Z axis 1204 trapezoidal screws. 13mm chrome plate shafts. Stepping motor type : 57 two-phase 1.45A-2A. Spindle motor: 300w dc motor. Principal axis collet: ER11/3.175 mm. Spindle speed : 300 8000rpm/min (PWM stepless speed regulation). Empty line speed: 0-2500mm/min (16 subdivided driving down). Spindle precision: radial beat acuities 0.03 mm. Control unit: triaxial one-piece drive + ring variable power + PWM speed. Carving Instructions: G code/TAB files/nc file/NCC files. Communication interface through USB Port with computer. Support system : Windows 7/ xp. Carving speed: 0-2000mm/min (different materials differ). Control unit :2.5A stepping motor driver plus adjustable spindle speed controller. Command code G code. Protection Emergency :stop button. Can be controlled by computer. Can control the engraving more precise. Emergency stop button enhance security. Large 3D engraving in soft wood, MDF board, native wood, PVC, Acrylic we suggest use one or two spiral flute ball bits. Can engraving much more materails by spiral flute bits, such as metal, steel, MDF board, solid wood, composite board plywood, stone. Spindle motor knob is useful for small positioning adjustment, with steady and strong support structure. The reinforced and thickened machine body make transportation absolutely to be safer and longer life time. The chrome shafts is not easy to deform, suitable for long time use. Flexible coupling can be used for high torque transmission. High Precision Stepping motor makes engraving more precise. 32-bit version of Windows 2000, Windows XP, Windows Vista, or Windows 7 (64-bit versions will not work). Non-integrated Video Card with 32MB RAM(Large G-code files, especially 3D files will require a video card with 512MB RAM or higher). MODEL Eight:USB 3 Axis CNC 3040 Router 400W. USB CNC ROUTER 3 axis 3040 400W ENGRAVER/ENGRAVING MILLING M/C 110AV. Reinforced and thickened machine body make transportation absolutely to be safer and longer life time. CNC3040 is suitble for Industry, Technology Research, Advertising Design, Arts Creation. Teaching, Student Project and Hobby Purposes. CNC3040 is a desktop CNC machine and designd for processing Industrial or Hobby. Prototype Building, Building Model Making, PCB. Adverstising Signs, Artwork, Crafts, Aircraft Models, RC Model parts, etc. So, you can do. Engraving work at office or home. Exquisite 3040 is a miniature version of mobile longmen structure of carving machine. Put on you computer is like puting a printer or scanner that coordination, and can. Completely as a compute peripherals tools, anywhere, anytime, help you to design intent fast real appear. This 3040 engraer is a user-friendly desktop engraving machine for those with limited space. And /or a limited budget. The Computerized CNC Engraving and Cutting Machine is suitable for various materials. Such as WOOD, PMMA or other plastic. MDF board, native wood, PVC, Acrylic, wood, composite board plywood, It can be used. Widely to process or make adverstising signs, PCB. Nameplates, badges, seals, bronzing plate, aluminium alloy, acryplates, ABS resin double. Color plate, PVC foaming board, indentation plates, signs. 3040T triaxial engraving machine part parameters. Effective working travel :275(X)mm385(Y)mm70(Z)mm. Work table dimension :320mm530mm. Frame materials :aluminum alloy 6063 and 6061. Leadscrew :1404 double thread Trapezoidal screws. X axis:1404 trapezoidal screws. Y axis:1404 trapezoidal screws. Z axis:1404 trapezoidal screws. Stepping motor type :57 two-phase 1.8A. Spindle motor :400w dc motor 5008000PRM/Min. Principal axis collet :ER11 / 3.175 mm. Repeat accuracy :0.05mm. Spindle precision :radial beat acuities 0.03 mm. Control unit :triaxial one-piece drive + ring variable power + PWM speed. Communication interface :through USB Port with computer. Support system :windows XP / win7. Operating Voltage: AC110V US PLUG. Control unit: 2.5A stepping motor driver plus adjustable spindle speed controller. Computer connection: on board palrallel port. Installment Support system is simple and intellgent. Feedback is very important to us. It is impossible to address issues if we do not know about them! Faction is our ultimate goal. We work hard to earn your trust and future business. A If you receive a defective item, you may return it or ask for a discount. Due to time zones, our reply to your questions may not be immediately. If it’s non-workdays, please kindly be patient and wait till Monday.

USB 4 Axis CNC 6040T Router Engraver Engraving Machine Carving Cutter 1.5KW VFD. This 6040T machine is suitable for industry, Technology Research. Advertising Design, Arts Creation, Teaching, Student Project and Hobby Purposes. It can work with various materials(metallic & non-metallic), such as: wood. Pmma or other plastic, MDF board, native wood, PVC, Acrylic, wood, composite. And soft metal, like aluminum, copper and silver to engrave. Them into 3D/2D works etc. It can used for engraving: advertising signs, PCB, nameplates, badges, seals. Bronzing plate, aluminum alloy, acrylic plates, ABS resin double color plate. PVC foaming board, indentation plates, signs, construction models. Instrument panels, wooden products, etc. The mini router Frame is movable. The machine can connect with computer. As other external device such as printer, scanner.. With the assist of the ROUTER 6040T, your design idea will be real-time display. X, Y, Z Working Area: 600(Y)390(X)120(Z)mm. Lathe structure: 6061/6063 Aluminium alloy. X axis—1605 Ball Screws. Y axis—1605 Ball Screws. Z axis—1204 Ball Screws. X axis—High intensity Chromeplate shaft. Y axis—High intensity Chromeplate shaft. Z axis—High intensity Chromeplate shaft. 1, Water cooled spindle motor can work longer time than air cooled motor. 2, Water cooled spindle motor has higher stability and better concentricity than air cooled motor. The spindle motor must connect with the VFD. It cannot directly connect with the supply voltage (AC110V). Please don’t change the data setting of the VFD if you are not professional technicians, or it might damage the spindle motor. Material: 304 stainless steel. Copper coil, Pressure cast aluminum pipe water jacket. 5A, 1.5 KW VFD. Spindle motor: 1.5 KW water cooled. Spindle speed: 24000 rpm. Max working frequency: 400Hz. Principal axis collet: ER11collet. Speed mode: By adjusting the VFD output voltage and operating frequency from 0-24000RPM. Lubrication way: lubricated by high grease. Repeat accuracy: 0.05mm. Spindle precision: radial beat acuities 0.03mm. Carving Instructions: G code / TAB files / nc file / NCC files. Communication interface: through USB connection with computer. Environment: windows XP / win7 32bits system. Working Speed: 50-1500mm / min (different material with different speed settings). Maximum Idle speed: 0-1500mm/min. Control unit: Toroidal transformer + PWM power supply module + TB6560 stepping motor drive. Computer connection: USB port. Command code: G code. Acceptable software: , EMC2. Protection: Emergency stop button. The NEW 1.5KW water-cooled VFD is available operating for long time, which can reinforced. The processing abilty of the machine and can be used to. Process aluminum alloy and hard wood. Water cooling spindle works more stable and durable. High quality accurate ball Screws drive make the engrving more precision. Anti-blackflash, high precision, long life circle. Assembling and locating the machine on steady desk well. Make sure that your computer has a 25pin USB port output. Place the contral box in a ventilated dry place where there is no dust, no moisture. Connecting the control box with the machine and you computer and make sure. The plug will not come off. Correctly connect the machine with the controller. Don’t suspended the cable which. Connect the Spindle motor with axis(X, Y, Z, A). Damage the driver of the controller. Correctly instal the Spindle motor and the heat pump. The heat pump should be covered. Completely in the water, then turned on the electric current to. Check whether the water-cooling system working well. Installing a control software and Drive on your computer. Fllowing our manual or guideline to set uo the software. Before turn on the machine, please check all the cable and water- cooling system to. Make sure they are working fine. You can enjoy making you dream with using our machine now. Feedback is very important to us. It is impossible to address issues if we do not know about them! Faction is our ultimate goal. We work hard to earn your trust and future business. A If you receive a defective item, you may return it or ask for a discount. Due to time zones, our reply to your questions may not be immediately. If it’s non-workdays, please kindly be patient and wait till Monday.

1.5KW 3/4 Axis 6040 CNC Router Desktop Engraver Milling / Drilling Machine NEW! 4 AXIS 1500W USB PORT. This CNC 6040T machine is suitable for industry, Technology Research, Advertising Design, Arts Creation, Teaching, Student Project and Hobby Purposes. It can work with various materials(metallic & non-metallic), such as: wood, pmma or other plastic, MDF board, native wood, PVC, Acrylic, wood, composite board plywood. And soft metal, like aluminum, copper and silver to engrave them into 3D/2D works etc. It can used for engraving: advertising signs, PCB, nameplates, badges, seals, bronzing plate, aluminum alloy, acrylic plates, ABS resin double color plate, PVC foaming board, indentation plates, signs, construction models. Instrument panels, wooden products, etc. The mini CNC router Frame is movable. The machine can connect with computer as other external device such as printer, scanner.. With the assist of the CNC ROUTER 6040T, your design idea will be real-time display. CNC engraving machine parameters. X, Y, Z Working Area: 600(Y)390. Lathe structure: 6061/6063 Aluminium alloy. Y axis—1605 Ball Screws. Z axis—1204 Ball Screws. X axis—High intensity Chromeplate shaft. Y axis—High intensity Chromeplate shaft. Z axis—High intensity Chromeplate shaft. The spindle motor must connect with the VFD. It cannot directly connect with the supply voltage (AC 220V). Please don’t change the data setting of the VFD if you are not professional technicians, or it might damage the spindle motor. Material: 304 stainless steel, Copper coil, Pressure cast aluminum pipe water jacket. VOLTS, current, power: AC 220V, 50Hz, 5A. 1.5 KW VFD. Spindle speed: 24000 rpm. Max working frequency: 400Hz. Principal axis collet: ER11collet, Standard configuration :6mm. Speed mode: By adjusting the VFD output voltage and operating frequency from 0-24000RPM. Lubrication way: lubricated by high grease. Repeat accuracy: 0.05mm. Spindle precision: radial beat acuities 0.03mm. Carving Instructions: G code / TAB files / nc file / NCC files. Communication interface: through USB connection with computer. Support system: windows XP / win7 32bits system. Carving speed: 0-2500mm/min(different materials differ). Operating Voltage: AC 220V. Control unit: Toroidal transformer + PWM power supply module + TB6560 stepping motor drive. Command code: G code. Protection: Emergency stop button. 1.5KW water-cooled VFD. Is available operating for long time, which can reinforced the processing ability of the machine and can be used to process aluminum alloy and hard wood. Water cooling spindle works more stable and durable. High quality accurate ball Screws drive make the engraving more precision. Anti-blackflash, high precision, long life circle. Assembling and locating the CNC machine on steady desk well. Make sure that your computer has a USB port output. Place the control box in a ventilated dry place where there is no dust, no moisture. Connecting the control box with the CNC machine and you computer and make sure the plug will not come off. Correctly connect the machine with the controller. Don’t suspended the cable which connect the Spindle motor with axis(X, Y, Z, A). It will damage the driver of the controller. Correctly install the Spindle motor and the heat pump. The heat pump should be covered completely in the water, then turned on the electric current to check whether the water-cooling system working well. Before turn on the machine, please check all the cable and water- cooling system to make sure they are working fine. You can enjoy making you dream with using our CNC machine now. 4 AXIS 1500W USB PORT+RC. Notes:Please prepare a computer with USB Interface. 1X main unit (Frame). 1X main unit (working base). 1X Sinal cable for A axis. 1X 25pin Parallel lines. 10X 47mm round head. 6X 410mm black Inner six angle screw with nut. 8X 520mm black Inner six angle screw. 4X 58mm Flat Philip’s head screw with nut and gasket. 8X 624mm BALCK FLAT Inner six angle screw. 2X six angle Wrench(3mm). 2X six angle Wrench(4mm). Suitable for PCB, wood, Plexiglass, PVC, Crystal Acrylic, RESIN, Plastic, SEALS, MDF, COMPOSITE, Aluminum material, Copper, Iron. It can work with various materials(metallic & non-metallic), such as: wood, pmma or other. Plastic, MDF board, native wood, PVC, Acrylic, wood, composite. Like aluminum, copper and silver to engrave them into. It can used for engraving: advertising signs, PCB, nameplates, badges, seals, bronzing plate, aluminum alloy, acrylic plates, ABS resin double color plate, PVC foaming board, indentation plates, signs, construction models, instrument panels, wooden products, etc. The machine can connect with computer as other. External device such as printer, scanner.. CNC Engraving Machine Parameters. X, Y, Z Working Area : 600(Y)390. Lathe structure : 6061/6063 Aluminum alloy. Y axis :1605 Ball Screws. Z axis:1204 Ball Screws. High intensity Chromeplate shaft. 1, The spindle motor must connect with the VFD. 2, It cannot directly connect with the supply voltage (AC110V). 3, Please don’t change the data setting of the VFD if you are not professional technicians, or it might damage the spindle motor. Pressure cast aluminum pipe water jacket. 5A, 1.5KW VFD. Spindle speed : 24000 rpm. Max working frequency : 400Hz. Principal axis collet: ER11collet. Speed mode:By adjusting the VFD output voltage and operating frequency. Repeat accuracy:0.05mm. Spindle precision:radial beat acuities 0.03mm. Communication interface:through USB connection with computer. Maximum Idle speed:1500mm/min. Working Speed :50-1500mm / min (different material with different speed settings). Control unit:Toroidal transformer + PWM power supply module + TB6560 stepping motor drive. Computer connection:USB port. Command code:G code. Protection:Emergency stop button. 1, The NEW 1.5KW water-cooled VFD is available operating for long time, which can reinforced the processing abil. Ty of the machine and can be used to. Process aluminum alloy and hard wood. 2, water cooling spindle works more stable and durable. 3, High quality accurate ball Screws drive make the engrving more precision. Make sure that your computer has a 25pin parallel port output. L box in a ventilated dry place where there is no dust, no moisture. Damage the driver of the controller. L the Spindle motor and the heat pump. The heat pump should be covered completely in the water, then turned on the electric current to. Check whether the water-cooling system working well. Waterproof design, very durable, anti-dirt, oil spray. Power by USB port. Dimensions: 22 x 8 x 3cm. The usb self-check light, you can type the ” scroll” on the keyboard to activate it. Directional motion control: X+, X-, Y+, Y-, Z+, Z-, A+, A. Feed rate control: F+, F. Jog rate: J+, J. Spindle speed: speed up, slow down. Programming: E-stop, cycle start, spindle on/off, Redo, single step, original point. 3 AXIS 1500W USB PORT. Suitable for PCB, wood, Plexi glass, PVC, Crystal Acrylic, RESIN, Plastic, SEALS, MDF, COMPOSITE, Aluminum material, Copper. This CNC 6040 machine is suitable for industry, Technology Research, Advertising Design, Arts Creation, Teaching, Student Project and Hobby Purposes. Like aluminum, copper and silver to engrave them into 3D/2D works etc. It can used for engraving: advertising signs, PCB, nameplates, badges, seals, bronzing plate, aluminum alloy, acrylic plates, ABS resin doublecolor plate, PVC foaming board, indentation plates, signs, construction models, instrument panels, wooden products, etc. Cnc engraving machine parameters. It cannot directly connect with the supply voltage (AC220V). VOLTS, current, power: AC110 /60Hz, 5A, 1.5KW VFD. Max working frequency: 60Hz. Support system: Windows XP/Win7. Computer connection: USB port. The NEW 1.5KW water-cooled VFD is available operating for long time, which can reinforced the processing abilty of the machine and can be used toprocess aluminum alloy and hard wood. High quality accurate ball Screws drive make the engrving more precision. Otherwise, It will damage the driver of the controller. The Spindle motor and the heat pump. Before turn on the machine, please check all the cable and water-cooling system to make sure they are working fine. (3 AXIS 1500W USB PORT+RC). Mode: By adjusting the VFD output voltage and operating frequency from 0-24000RPM. Is available operating for long time, which can reinforced the processing abil. High quality accurate ball Screws drive make the engr. Flash, high precision, long life circle. (3 AXIS 1500W Parallel Port). Notes:Please prepare a computer with DB25 parallel Interface. This machine needs to connect to a computer through its controller box with a. Parallel cable (both included). It is not recommended to connect to a notebook through a. Parallel port as the power saving features tend to interrupt the data flow. It is also not recommended to connect to a computers with 64 bit versions of Windows due to problems with the Parallel port driver. Suitable for PCB, wood, Plexiglass, PVC, Crystal Acrylic, RESIN, Plastic, SEALS, MDF, COMPOSITE, Aluminum material, Copper. Lathe structure:6061/6063 Aluminium alloy. Y axis:1204 Ball Screws. X axis:High intensity Chromeplate shaft. Y axis:High intensity Chromeplate shaft. Z axis:High intensity Chromeplate shaft. Material:304 stainless steel. Spindle speed:24000 rpm. Max working frequency:400Hz. Principal axis collet:ER11collet. Mode:By adjusting the VFD output voltage and operating frequency from 0-24000RPM. Lubrication way:lubricated by high grease. Carving Instructions:G code / TAB files / nc file / NCC files. Communication interface:through parallel connection with computer. Support system:windows XP / win7. Toroidal transformer + PWM power supply module + TB6560 stepping motor drive. 3, High quality accurate ball Screws drive make the engr. Connecting the control box with the CNC machine and you computer. And make sure the plug will not come off. (3 AXIS 1500W Parallel Port+RC). Notes: Please prepare a computer with DB25 parallel Interface. PCB, wood, Plexiglass, PVC, Crystal Acrylic, RESIN, Plastic, SEALS, MDF, COMPOSITE, Aluminum material, Copper. This 6040T machine is suitable for industry, Technology Research, Advertising Design, Arts Creation, Teaching, Student Project and Hobby Purposes. The mini router Frame is movable. With the assist of the ROUTER 6040T, your design idea will be real-time display. Y axis–1605 Ball Screws. Z axis–1204 Ball Screws. X axis–High intensity Chromeplate shaft. Y axis–High intensity Chromeplate shaft. Z axis–High intensity Chromeplate shaft. It cannot directly connect with the supply voltage (AC110V). VOLTS, current, power: AC110 /60Hz, 5A. Principal axis collet: ER11collet, Standard configuration: 6mm. Communication interface: through parallel connection with computer. Environment: Windows XP / Win7, 32bits system. Computer connection: Parallel port. 1.5 KW water-cooled VFD. Ty of the machine and can be used to process aluminum alloy and hard wood. Compatability: fit for Type3/ArtCAMParameter. Assembling and locating the machine on steady desk well. Connecting the control box with the machine and you computer and make sure the plug will not come off. Installing a control Drive on your computer. Llowing our manual or guideline to set. You can enjoy making you dream with using our machine now. (5 AXIS 1500W USB Port). Make sure that your computer has a 25pin USB port output. Don’t suspended the cable which connect the Spindle motor with axis(X, Y, Z, A, B). Highlights of water cooling system. It can cool the spindle and protect the machine. Avoid the spindle burn out. Can engrave the high hardness or metal. It can improve the efficiency and accuracy of the machine. 2X Sinal cable for A B axis. This 6040T machine is suitable for industry, Technology Research. Advertising Design, Arts Creation, Teaching, Student Project and Hobby Purposes. With the assist of the ROUTER 6040, your design idea will be real-time display. X, Y, Z Working Area:600(Y)390. Y axis:1605 Ball Screws. Material:304 stainless steel, Copper coil, Pressure cast aluminum pipe water jacket. Speed mode:By adjusting the VFD output voltage and operating frequency:from 0-24000RPM. Software environment:32-bit version of Windows 2000, Windows XP, Windows Vista, or Windows 7 (64-bit versions will not work). Non-integrated Video Card with 32MB RAM(Large G-code files, especially 3D files will require a video card with 512MB RAM or higher). 50-1500mm/min(different material with different speed settings). Anti-black flash, high precision, long life circle. Note:We only sell machine without software. Feedback is very important to us. It is impossible to address issues if we do not know about them! Faction is our ultimate goal. We work hard to earn your trust and future business. A If you receive a defective item, you may return it or ask for a discount. Due to time zones, our reply to your questions may not be immediately. If it’s non-workdays, please kindly be patient and wait till Monday. Creative Design, Durable Material, Beautiful Appearance. ?? Easy installation, Good Performance??? Good Quality Guarantee, Long Service Life? Drilling, Milling, Engraving, Cutting, Carving. Easy installation, Convenient Use, Easy Operation.

USB 4 Axis 1.5KW VFD CNC Router 6040Z Engraver Engraving Machine Woodworking. This 6040T machine is suitable for industry, Technology Research. Advertising Design, Arts Creation, Teaching, Student Project and Hobby Purposes. It can work with various materials(metallic & non-metallic), such as: wood. Pmma or other plastic, MDF board, native wood, PVC, Acrylic, wood, composite. And soft metal, like aluminum, copper and silver to engrave. Them into 3D/2D works etc. It can used for engraving: advertising signs, PCB, nameplates, badges, seals. Bronzing plate, aluminum alloy, acrylic plates, ABS resin double color plate. PVC foaming board, indentation plates, signs, construction models. Instrument panels, wooden products, etc. The mini router Frame is movable. The machine can connect with computer. As other external device such as printer, scanner.. With the assist of the ROUTER 6040T, your design idea will be real-time display. X, Y, Z Working Area: 600(Y)390(X)120(Z)mm. Lathe structure: 6061/6063 Aluminium alloy. X axis—1605 Ball Screws. Y axis—1605 Ball Screws. Z axis—1204 Ball Screws. X axis—High intensity Chromeplate shaft. Y axis—High intensity Chromeplate shaft. Z axis—High intensity Chromeplate shaft. 1, Water cooled spindle motor can work longer time than air cooled motor. 2, Water cooled spindle motor has higher stability and better concentricity than air cooled motor. The spindle motor must connect with the VFD. It cannot directly connect with the supply voltage (AC110V). Please don’t change the data setting of the VFD if you are not professional technicians, or it might damage the spindle motor. Material: 304 stainless steel. Copper coil, Pressure cast aluminum pipe water jacket. 5A, 1.5 KW VFD. Spindle motor: 1.5 KW water cooled. Spindle speed: 24000 rpm. Max working frequency: 400Hz. Principal axis collet: ER11collet. Speed mode: By adjusting the VFD output voltage and operating frequency from 0-24000RPM. Lubrication way: lubricated by high grease. Repeat accuracy: 0.05mm. Spindle precision: radial beat acuities 0.03mm. Carving Instructions: G code / TAB files / nc file / NCC files. Communication interface: through USB connection with computer. Environment: windows XP / win7 32bits system. Working Speed: 50-1500mm / min (different material with different speed settings). Maximum Idle speed: 0-1500mm/min. Control unit: Toroidal transformer + PWM power supply module + TB6560 stepping motor drive. Computer connection: USB port. Command code: G code. Protection: Emergency stop button. The NEW 1.5KW water-cooled VFD is available operating for long time, which can reinforced. The processing abilty of the machine and can be used to. Process aluminum alloy and hard wood. Water cooling spindle works more stable and durable. High quality accurate ball Screws drive make the engrving more precision. Anti-blackflash, high precision, long life circle. Assembling and locating the machine on steady desk well. Make sure that your computer has a 25pin USB port output. Place the contral box in a ventilated dry place where there is no dust, no moisture. Connecting the control box with the machine and you computer and make sure. The plug will not come off. Correctly connect the machine with the controller. Don’t suspended the cable which. Connect the Spindle motor with axis(X, Y, Z, A). Damage the driver of the controller. Correctly instal the Spindle motor and the heat pump. The heat pump should be covered. Completely in the water, then turned on the electric current to. Check whether the water-cooling system working well. Installing a control software and Drive on your computer. Fllowing our manual or guideline to set uo the software. Before turn on the machine, please check all the cable and water- cooling system to. Make sure they are working fine. You can enjoy making you dream with using our machine now. Feedback is very important to us. It is impossible to address issues if we do not know about them! Faction is our ultimate goal. We work hard to earn your trust and future business. A If you receive a defective item, you may return it or ask for a discount. Due to time zones, our reply to your questions may not be immediately. If it’s non-workdays, please kindly be patient and wait till Monday. 6040 ROUTER ENGRAVING MACHINE. Toroidal transformer + PWM power supply module + T. Windows XP / win7 32bits system. 1.5KW Water Cooled Spindle Motor. X, Y, Z Working Area. 600(Y)390(X)120(Z)mm.

3/4/5 Axis 1.5KW 3D 6040 CNC Router Desktop Engraver Milling / Drilling Machine. 4 AXIS 1500W USB PORT. This CNC 6040T machine is suitable for industry, Technology Research, Advertising Design, Arts Creation, Teaching, Student Project and Hobby Purposes. It can work with various materials(metallic & non-metallic), such as: wood, pmma or other plastic, MDF board, native wood, PVC, Acrylic, wood, composite board plywood. And soft metal, like aluminum, copper and silver to engrave them into 3D/2D works etc. It can used for engraving: advertising signs, PCB, nameplates, badges, seals, bronzing plate, aluminum alloy, acrylic plates, ABS resin double color plate, PVC foaming board, indentation plates, signs, construction models. Instrument panels, wooden products, etc. The mini CNC router Frame is movable. The machine can connect with computer as other external device such as printer, scanner.. With the assist of the CNC ROUTER 6040T, your design idea will be real-time display. CNC engraving machine parameters. X, Y, Z Working Area: 600(Y)390. Lathe structure: 6061/6063 Aluminium alloy. Y axis—1605 Ball Screws. Z axis—1204 Ball Screws. X axis—High intensity Chromeplate shaft. Y axis—High intensity Chromeplate shaft. Z axis—High intensity Chromeplate shaft. The spindle motor must connect with the VFD. It cannot directly connect with the supply voltage (AC 220V). Please don’t change the data setting of the VFD if you are not professional technicians, or it might damage the spindle motor. Material: 304 stainless steel, Copper coil, Pressure cast aluminum pipe water jacket. VOLTS, current, power: AC 220V, 50Hz, 5A. 1.5 KW VFD. Spindle speed: 24000 rpm. Max working frequency: 400Hz. Principal axis collet: ER11collet, Standard configuration :6mm. Speed mode: By adjusting the VFD output voltage and operating frequency from 0-24000RPM. Lubrication way: lubricated by high grease. Repeat accuracy: 0.05mm. Spindle precision: radial beat acuities 0.03mm. Carving Instructions: G code / TAB files / nc file / NCC files. Communication interface: through USB connection with computer. Support system: windows XP / win7 32bits system. Carving speed: 0-2500mm/min(different materials differ). Operating Voltage: AC 220V. Control unit: Toroidal transformer + PWM power supply module + TB6560 stepping motor drive. Command code: G code. Protection: Emergency stop button. 1.5KW water-cooled VFD. Is available operating for long time, which can reinforced the processing ability of the machine and can be used to process aluminum alloy and hard wood. Water cooling spindle works more stable and durable. High quality accurate ball Screws drive make the engraving more precision. Anti-blackflash, high precision, long life circle. Assembling and locating the CNC machine on steady desk well. Make sure that your computer has a USB port output. Place the control box in a ventilated dry place where there is no dust, no moisture. Connecting the control box with the CNC machine and you computer and make sure the plug will not come off. Correctly connect the machine with the controller. Don’t suspended the cable which connect the Spindle motor with axis(X, Y, Z, A). It will damage the driver of the controller. Correctly install the Spindle motor and the heat pump. The heat pump should be covered completely in the water, then turned on the electric current to check whether the water-cooling system working well. Before turn on the machine, please check all the cable and water- cooling system to make sure they are working fine. You can enjoy making you dream with using our CNC machine now. 4 AXIS 1500W USB PORT+RC. Notes:Please prepare a computer with USB Interface. 1X main unit (Frame). 1X main unit (working base). 1X Sinal cable for A axis. 1X 25pin Parallel lines. 10X 47mm round head. 6X 410mm black Inner six angle screw with nut. 8X 520mm black Inner six angle screw. 4X 58mm Flat Philip’s head screw with nut and gasket. 8X 624mm BALCK FLAT Inner six angle screw. 2X six angle Wrench(3mm). 2X six angle Wrench(4mm). Suitable for PCB, wood, Plexiglass, PVC, Crystal Acrylic, RESIN, Plastic, SEALS, MDF, COMPOSITE, Aluminum material, Copper, Iron. It can work with various materials(metallic & non-metallic), such as: wood, pmma or other. Plastic, MDF board, native wood, PVC, Acrylic, wood, composite. Like aluminum, copper and silver to engrave them into. It can used for engraving: advertising signs, PCB, nameplates, badges, seals, bronzing plate, aluminum alloy, acrylic plates, ABS resin double color plate, PVC foaming board, indentation plates, signs, construction models, instrument panels, wooden products, etc. The machine can connect with computer as other. External device such as printer, scanner.. CNC Engraving Machine Parameters. X, Y, Z Working Area : 600(Y)390. Lathe structure : 6061/6063 Aluminum alloy. Y axis :1605 Ball Screws. Z axis:1204 Ball Screws. High intensity Chromeplate shaft. 1, The spindle motor must connect with the VFD. 2, It cannot directly connect with the supply voltage (AC110V). 3, Please don’t change the data setting of the VFD if you are not professional technicians, or it might damage the spindle motor. Pressure cast aluminum pipe water jacket. 5A, 1.5KW VFD. Spindle speed : 24000 rpm. Max working frequency : 400Hz. Principal axis collet: ER11collet. Speed mode:By adjusting the VFD output voltage and operating frequency. Repeat accuracy:0.05mm. Spindle precision:radial beat acuities 0.03mm. Communication interface:through USB connection with computer. Maximum Idle speed:1500mm/min. Working Speed :50-1500mm / min (different material with different speed settings). Control unit:Toroidal transformer + PWM power supply module + TB6560 stepping motor drive. Computer connection:USB port. Command code:G code. Protection:Emergency stop button. 1, The NEW 1.5KW water-cooled VFD is available operating for long time, which can reinforced the processing abil. Ty of the machine and can be used to. Process aluminum alloy and hard wood. 2, water cooling spindle works more stable and durable. 3, High quality accurate ball Screws drive make the engrving more precision. Make sure that your computer has a 25pin parallel port output. L box in a ventilated dry place where there is no dust, no moisture. Damage the driver of the controller. L the Spindle motor and the heat pump. The heat pump should be covered completely in the water, then turned on the electric current to. Check whether the water-cooling system working well. Waterproof design, very durable, anti-dirt, oil spray. Power by USB port. Dimensions: 22 x 8 x 3cm. The usb self-check light, you can type the ” scroll” on the keyboard to activate it. Directional motion control: X+, X-, Y+, Y-, Z+, Z-, A+, A. Feed rate control: F+, F. Jog rate: J+, J. Spindle speed: speed up, slow down. Programming: E-stop, cycle start, spindle on/off, Redo, single step, original point. 3 AXIS 1500W USB PORT. Suitable for PCB, wood, Plexi glass, PVC, Crystal Acrylic, RESIN, Plastic, SEALS, MDF, COMPOSITE, Aluminum material, Copper. This CNC 6040 machine is suitable for industry, Technology Research, Advertising Design, Arts Creation, Teaching, Student Project and Hobby Purposes. Like aluminum, copper and silver to engrave them into 3D/2D works etc. It can used for engraving: advertising signs, PCB, nameplates, badges, seals, bronzing plate, aluminum alloy, acrylic plates, ABS resin doublecolor plate, PVC foaming board, indentation plates, signs, construction models, instrument panels, wooden products, etc. Cnc engraving machine parameters. It cannot directly connect with the supply voltage (AC220V). VOLTS, current, power: AC110 /60Hz, 5A, 1.5KW VFD. Max working frequency: 60Hz. Support system: Windows XP/Win7. Computer connection: USB port. The NEW 1.5KW water-cooled VFD is available operating for long time, which can reinforced the processing abilty of the machine and can be used toprocess aluminum alloy and hard wood. High quality accurate ball Screws drive make the engrving more precision. Otherwise, It will damage the driver of the controller. The Spindle motor and the heat pump. Before turn on the machine, please check all the cable and water-cooling system to make sure they are working fine. (3 AXIS 1500W USB PORT+RC). Mode: By adjusting the VFD output voltage and operating frequency from 0-24000RPM. Is available operating for long time, which can reinforced the processing abil. High quality accurate ball Screws drive make the engr. Flash, high precision, long life circle. (3 AXIS 1500W Parallel Port). Notes:Please prepare a computer with DB25 parallel Interface. This machine needs to connect to a computer through its controller box with a. Parallel cable (both included). It is not recommended to connect to a notebook through a. Parallel port as the power saving features tend to interrupt the data flow. It is also not recommended to connect to a computers with 64 bit versions of Windows due to problems with the Parallel port driver. Suitable for PCB, wood, Plexiglass, PVC, Crystal Acrylic, RESIN, Plastic, SEALS, MDF, COMPOSITE, Aluminum material, Copper. Lathe structure:6061/6063 Aluminium alloy. Y axis:1204 Ball Screws. X axis:High intensity Chromeplate shaft. Y axis:High intensity Chromeplate shaft. Z axis:High intensity Chromeplate shaft. Material:304 stainless steel. Spindle speed:24000 rpm. Max working frequency:400Hz. Principal axis collet:ER11collet. Mode:By adjusting the VFD output voltage and operating frequency from 0-24000RPM. Lubrication way:lubricated by high grease. Carving Instructions:G code / TAB files / nc file / NCC files. Communication interface:through parallel connection with computer. Support system:windows XP / win7. Toroidal transformer + PWM power supply module + TB6560 stepping motor drive. 3, High quality accurate ball Screws drive make the engr. Connecting the control box with the CNC machine and you computer. And make sure the plug will not come off. (3 AXIS 1500W Parallel Port+RC). Notes: Please prepare a computer with DB25 parallel Interface. PCB, wood, Plexiglass, PVC, Crystal Acrylic, RESIN, Plastic, SEALS, MDF, COMPOSITE, Aluminum material, Copper. This 6040T machine is suitable for industry, Technology Research, Advertising Design, Arts Creation, Teaching, Student Project and Hobby Purposes. The mini router Frame is movable. With the assist of the ROUTER 6040T, your design idea will be real-time display. Y axis–1605 Ball Screws. Z axis–1204 Ball Screws. X axis–High intensity Chromeplate shaft. Y axis–High intensity Chromeplate shaft. Z axis–High intensity Chromeplate shaft. It cannot directly connect with the supply voltage (AC110V). VOLTS, current, power: AC110 /60Hz, 5A. Principal axis collet: ER11collet, Standard configuration: 6mm. Communication interface: through parallel connection with computer. Environment: Windows XP / Win7, 32bits system. Computer connection: Parallel port. 1.5 KW water-cooled VFD. Ty of the machine and can be used to process aluminum alloy and hard wood. Compatability: fit for Type3/ArtCAMParameter. Assembling and locating the machine on steady desk well. Connecting the control box with the machine and you computer and make sure the plug will not come off. Installing a control Drive on your computer. Llowing our manual or guideline to set. You can enjoy making you dream with using our machine now. (5 AXIS 1500W USB Port). Make sure that your computer has a 25pin USB port output. Don’t suspended the cable which connect the Spindle motor with axis(X, Y, Z, A, B). Highlights of water cooling system. It can cool the spindle and protect the machine. Avoid the spindle burn out. Can engrave the high hardness or metal. It can improve the efficiency and accuracy of the machine. 2X Sinal cable for A B axis. This 6040T machine is suitable for industry, Technology Research. Advertising Design, Arts Creation, Teaching, Student Project and Hobby Purposes. With the assist of the ROUTER 6040, your design idea will be real-time display. X, Y, Z Working Area:600(Y)390. Y axis:1605 Ball Screws. Material:304 stainless steel, Copper coil, Pressure cast aluminum pipe water jacket. Speed mode:By adjusting the VFD output voltage and operating frequency:from 0-24000RPM. Software environment:32-bit version of Windows 2000, Windows XP, Windows Vista, or Windows 7 (64-bit versions will not work). Non-integrated Video Card with 32MB RAM(Large G-code files, especially 3D files will require a video card with 512MB RAM or higher). 50-1500mm/min(different material with different speed settings). Anti-black flash, high precision, long life circle. Note:We only sell machine without software. Feedback is very important to us. It is impossible to address issues if we do not know about them! Faction is our ultimate goal. We work hard to earn your trust and future business. A If you receive a defective item, you may return it or ask for a discount. Due to time zones, our reply to your questions may not be immediately. If it’s non-workdays, please kindly be patient and wait till Monday.

3/4 Axis CNC Router Engraver Machine Drill Woodwork 3D Cutting USB+Remote 1.5KW. 3 Axis CNC 6040 1500W Parallel +RC. SKU:3-1.5KW6040A+3-1.5KW6040B+TS007. Notes:Please prepare a computer with DB25 parallel Interface. Suitable for PCB, wood, Plexiglass, PVC, Crystal Acrylic, RESIN, Plastic, SEALS, MDF, COMPOSITE. This CNC 6040T machine is suitable for industry, Technology Research, Advertising Design. Arts Creation, Teaching, Student Project and Hobby Purposes. It can work with various materials(metallic & non-metallic), such as: wood, pmma or other plastic. MDF board, native wood, PVC, Acrylic, wood, composite board plywood. Copper and silver to engrave them into 3D/2D works etc. It can used for engraving: advertising signs, PCB, nameplates, badges, seals, bronzing plate. Aluminum alloy, acrylic plates, ABS resin double color plate, PVC foaming board, indentation plates, signs, construction models, instrument panels, wooden products, etc. The mini CNC router Frame is movable. The machine can connect with computer as. Other external device such as printer, scanner.. With the assist of the CNC ROUTER 6040T, your design idea will be real-time display. CNC engraving machine parameters. X, Y, Z Working Area: 600(Y)390(X)120(Z)mm. Outside dimension:865680570mm(LWH). Table size:770(Y)490(X)mm. Lathe structure:6061/6063 Aluminium alloy. X axis:1204 Ball Screws. Y axis:1204 Ball Screws. Z axis:1204 Ball Screws. X axis:High intensity Chromeplate shaft. Y axis:High intensity Chromeplate shaft. Z axis:High intensity Chromeplate shaft. 1, The spindle motor must connect with the VFD. 2, It cannot directly connect with the supply voltage (AC110V). 3, Please don’t change the data setting of the VFD if you are not professional technicians, or it might damage the spindle motor. Material:304 stainless steel, Copper coil, Pressure cast aluminum pipe water jacket. AC110 /50Hz, 5A, 1.5KW VFD. Spindle speed:24000 rpm. Max working frequency:400Hz. Principal axis collet:ER11collet, Standard configuration :6mm. Mode:By adjusting the VFD output voltage and operating frequency. Lubrication way:lubricated by high grease. Repeat accuracy:0.05mm. Spindle precision:radial beat acuities 0.03mm. Carving Instructions:G code / TAB files / nc file / NCC files. Communication interface:through parallel connection with computer. Support system:windows XP / win7. Maximum Idle speed:1500mm/min. Working Speed :50-1500mm / min (different material with different speed settings). Control unit:Toroidal transformer + PWM power supply module + TB6560 stepping motor drive. Command code:G code. Protection:Emergency stop button. Waterproof design, very durable, anti-dirt, oil spray. Power by USB port. Dimensions: 22 x 8 x 3cm The usb self-check light, you can type the ” scroll” on the keyboard to activate it. Directional motion control: X+, X-, Y+, Y-, Z+, Z-, A+, A. Feed rate control: F+, F. Jog rate: J+, J. Spindle speed: speed up, slow down. Programming: E-stop, cycle start, spindle on/off, Redo, single step, original point. 1, The NEW 1.5KW water-cooled VFD is available operating for long time, which can reinforced the processing abilty of the machine and can be used toprocess aluminum alloy and hard wood. 2, water cooling spindle works more stable and durable. 3, High quality accurate ball Screws drive make the engrving more precision. Anti-blackflash, high precision, long life circle. Assembling and locating the CNC machine on steady desk well. Make sure that your computer has a 25pin parallel port output. Place the contral box in a ventilated dry place where there is no dust, no moisture. Connecting the control box with the CNC machine and you computer. And make sure the plug will not come off. Correctly connect the machine with the controller. 3 Axis CNC 6040 1500W USB +RC. 3 AXIS CNC Router 6040 Engraver Engraving Mill&Drill 3D CUTTER. It is also not recommended to connect to a computers with 64 bit versions of Windows due to problems with the usb port driver. Suitable for PCB, wood, Plexi glass, PVC, Crystal Acrylic, RESIN, Plastic, SEALS, MDF, COMPOSITE, Aluminum material, Copper. This CNC 6040 machine is suitable for industry, Technology Research, Advertising Design, Arts Creation, Teaching, Student Project and Hobby Purposes. It can work with various materials(metallic & non-metallic), such as: wood, pmma or other plastic, MDF board, native wood, PVC, Acrylic, wood, composite board plywood. Like aluminum, copper and silver to engrave them into 3D/2D works etc. It can used for engraving: advertising signs, PCB, nameplates, badges, seals, bronzing plate, aluminum alloy, acrylic plates, ABS resin doublecolor plate, PVC foaming board, indentation plates, signs, construction models, instrument panels, wooden products, etc. The machine can connect with computer as other external device such as printer, scanner.. Cnc engraving machine parameters. Outside dimension: 865680570mm(LWH). Table size: 770(Y)490(X)mm. Lathe structure: 6061/6063 Aluminium alloy. X axis—1605 Ball Screws. Y axis—1605 Ball Screws. X axis—High intensity Chromeplate shaft. Y axis—High intensity Chromeplate shaft. Z axis—High intensity Chromeplate shaft. The spindle motor must connect with the VFD. It cannot directly connect with the supply voltage (AC220V). Please don’t change the data setting of the VFD if you are not professional technicians, or it might damage the spindle motor. Material: 304 stainless steel, Copper coil, Pressure cast aluminum pipe water jacket. VOLTS, current, power: AC110 /60Hz, 5A, 1.5KW VFD. 1, Water cooled spindle motor can work longer time than air cooled motor. 2, Water cooled spindle motor has higher stability and better concentricity than air cooled motor. Spindle speed: 24000 rpm. Max working frequency: 60Hz. Principal axis collet: ER11collet, Standard configuration :6mm. Mode: By adjusting the VFD output voltage and operating frequency from 0-24000RPM. Lubrication way: lubricated by high grease. Repeat accuracy: 0.05mm. Spindle precision: radial beat acuities 0.03mm. Carving Instructions: G code / TAB files / nc file / NCC files. Communication interface: through USB connection with computer. Support system: Windows XP/Win7(32bit). Control unit: Toroidal transformer + PWM power supply module + TB6560 stepping motor drive. Computer connection: USB port. Command code: G code. Protection: Emergency stop button. The NEW 1.5KW water-cooled VFD is available operating for long time, which can reinforced the processing abilty of the machine and can be used toprocess aluminum alloy and hard wood. Water cooling spindle works more stable and durable. High quality accurate ball Screws drive make the engrving more precision. Make sure that your computer has a USB port output. Connecting the control box with the CNC machine and you computer and make sure the plug will not come off. Don’t suspended the cable which connect the Spindle motor with axis(X, Y, Z, A). Otherwise, It will damage the driver of the controller. Correctly instal the Spindle motor and the heat pump. The heat pump should be covered completely in the water, then turned on the electric current to check whether the water-cooling system working well. Before turn on the machine, please check all the cable and water-cooling system to make sure they are working fine. You can enjoy making you dream with using our CNC machine now. If you have any problem. 3 Axis CNC 6040 1500W Parallel. Notes: Please prepare a computer with DB25 parallel Interface. Suitable for PCB, wood, Plexiglass, PVC, Crystal Acrylic, RESIN, Plastic, SEALS, MDF, COMPOSITE, Aluminum material, Copper. This 6040T machine is suitable for industry, Technology Research, Advertising Design, Arts Creation, Teaching, Student Project and Hobby Purposes. It can work with various materials(metallic & non-metallic), such as: wood, pmma or other plastic, MDF board, native wood, PVC, Acrylic, wood, composite. It can used for engraving: advertising signs, PCB, nameplates, badges, seals, bronzing plate, aluminum alloy, acrylic plates, ABS resin double color plate. PVC foaming board, indentation plates, signs, construction models, instrument panels, wooden products, etc. The mini router Frame is movable. With the assist of the ROUTER 6040T, your design idea will be real-time display. X axis–1605 Ball Screws. Y axis–1605 Ball Screws. Z axis–1204 Ball Screws. X axis–High intensity Chromeplate shaft. Y axis–High intensity Chromeplate shaft. Z axis–High intensity Chromeplate shaft. It cannot directly connect with the supply voltage (AC110V). Spindle motor:1.5 KW water cooled. Max working frequency: 400Hz. Principal axis collet: ER11collet, Standard configuration: 6mm. Speed mode: By adjusting the VFD output voltage and operating frequency. Communication interface: through parallel connection with computer. Environment: Windows XP / Win7 32bits system. Working Speed: 50-1500mm / min (different material with different speed settings). Maximum Idle speed: 0-1500mm/min. Computer connection: Parallel port. The NEW 1.5 KW water-cooled VFD is available operating for long time, which can reinforced the processing abilty of the machine and can be used to. Process aluminum alloy and hard wood. Assembling and locating the machine on steady desk well. Connecting the control box with the machine and you computer and make sure the plug will not come off. Damage the driver of the controller. The heat pump should be covered completely in the water, then turned on the electric current to. Check whether the water-cooling system working well. Installing a control software and Driveon your computer. Fllowing our manual or guideline to set uo the software. Before turn on the machine, please check all the cable and water- cooling system to make sure they are working fine. You can enjoy making you dream with using our machine now. 3 Axis CNC 6040 1500W USB. USB 3-Axis CNC 6040 Router Engraver 3 Rotating Axis Metal Wood Cut Machine 1.5KW. Note:We only sell machine without software. PCB, wood, Plexi glass, PVC, Crystal Acrylic, RESIN, Plastic, SEALS, MDF, COMPOSITE, Aluminum material, Copper. This 6040 machine is suitable for industry, Technology Research, Advertising Design. Arts Creation, Teaching, Student Project and Hobby. It can work with various materials(metallic & non-metallic), such as: wood. Pmma or other plastic, MDF board, native wood, PVC, Acrylic, wood, composite. Like aluminum, copper and silver to engrave. Them into 3D/2D works etc. It can used for engraving: advertising signs, PCB, nameplates, badges. Seals, bronzing plate, aluminum alloy, acrylic plates, ABS resin double. PVC foaming board, indentation plates, signs, construction. Models, instrument panels, wooden products, etc. The machine can connect with computer. As other external device such as printer, scanner.. With the assist of the ROUTER 6040T, your design idea will be real-time. Z axis—1204 Ball Screws. Speed mode: By adjusting the VFD output voltage and operating frequency from 0-24000RPM. The NEW 1.5KW water-cooled VFD is available operating for long time, which. Can reinforced the processing. Abilty of the machine and can be used to. High quality accurate ball Screws drive make the engrving more. Place the contral box in a ventilated dry place where there is no dust, no. Connecting the control box with the machine and you computer and make. Sure the plug will not come off. Don’t suspended the. Cable which connect the Spindle motor with axis(X, Y, Z, A). The heat pump should. Be covered completely in the water, then turned on the electric current to. Installing a control software and Drive. Before turn on the machine, please check all the cable and water-cooling. System to make sure they are working fine. We will gladly assist you. 4 Axis CNC 6090 2200W USB. 6090 router 4 Axis+2.2kw Spindle motor +VFD +USB Port Metal Wood. Engraver with tool sensor. X axis: SFU1605 Ball Screws. Y axis: SFU1605 Ball Screws. Z axis: SFU1204 Ball Screws. Router engraving machine parameters. Outside dimension: 1150x970x650mm(LxWxH). Working platform size: 1045x720mm(LxW). Frame Material: The whole machine used 6061 aluminum profiles. Feeding height: =140mm(From base of Z axis to platform). X, Y, Z Working Area: 600x900x150mm. X axis: ø20 High intensity round rail. Y axis: SBRø20 high-strength aluminum base rails. Z axis: ø12 high-strength round rail. Stepping motor: two-phase 3A (with handwheels). Driving Power for Stepping motor: AC110, Output DC 24V, 10A. Maximum Idle speed: 1500mm/m. Working Speed: 50-1500mm/min (different material with different speed settings). Spindle motor: 2200Whigh-speed variable frequency spindle motor, ER20 chuck, matching 6mm bur. 2, Water cooled spindle motor has higher stability and better concentricity than. Variable-frequency Drive(VFD): AC110V, 2200W, 0-400Hz (built-in Control box). Drive of Stepping motor. 0-3.5A adjustable four-axis driveTB6560AHQchip, 24V power supply, 2, 4, 8, 16 Subdivision. Settings, Factory setting: 8 subdivided. Repositioning precision: =0.05mm. Cooling method: Water cooling, Matching heat dissipation water pump. Spindle precision: Radial runout=0.03mm. Carving command:G code/TAB file/nc/TAB /NCC/file. Communication interface: through USB PORT connect with computer. Gross weight of machine. Update function: with limit switch. Woodworking industry: sculpture, round carving, wooden handicraft processing. Advertising signs: logo making, cutting acrylic, plastic molding, suit for making a variety of materials advertising decorative products. Other industries: The engraver could do shadow-carved, sculpture which widely used in the gift industry; can be used in aluminum cutting industry, such as aluminum, aluminum-plastic plate, aluminum honeycomb panels, aluminum, 3D engraving process, Artificial plate, cutting LED and neon letter, making plastic light box model; also can engrave on acrylic, copper, PVC board, artificial stone, MDF board, and other metal sheet. The NEW 2.2KW water-cooled VFD is available operating for long time, which can reinforced the processing ability of the machine and can be used to engrave on aluminum alloy and hard wood. Assembling and locating the Engraving machine on steady desk well. Place the control box in a ventilated dry place where there is no dust, no moisture. Connecting the control box with the Engraving machine and you computer and make sure the plug will not come off. Otherwise, it will damage the driver of the controller. You can enjoy making you dream with using our Engraving machine now. 1X main unit (Frame). 1X main unit (working base). 1X Sinal cable for A axis. 10X 47mm round head. 6X 410mm black Inner six angle screw with nut. 8X 520mm black Inner six angle screw. 4X 58mm Flat Philip’s head screw with nut and gasket. 8X 624mm BALCK FLAT Inner six angle screw. 2X six angle Wrench(3mm). 2X six angle Wrench(4mm). 1x Tools Setting Auto-Check Instrument for Engraving Machine. 4 Axis CNC 6090 2200W USB+RC. CNC 6090 router 4Axis+2.2kw Spindle motor +VFD +USB Port Metal Wood Engraver with tool sensor Package list: 1X main unit (Frame) 1X main unit (working base) 2X Fence baffle 1X control box 1X A axis 1X Sinal cable for A axis 1X pump 1X USB cable 2X cutter 26mm 2X cutter 36mm 10X 47mm round head 6X 410mm black Inner six angle screw with nut 8X 520mm black Inner six angle screw 4X 58mm Flat Philip’s head screw with nut and gasket 8X 624mm BALCK FLAT Inner six angle screw 12X Aluminium fastener 1X 13-15# Wrench 1X 14-17# Wrench 2X six angle Wrench(3mm) 2X six angle Wrench(4mm) 1X Teflon tape 2X Fuse (5A) 1X Power cable 1X Manual. 1x Tools Setting Auto-Check Instrument for CNC. CNC Router engraving machine parameters: Model:CNC6090GZ Outside dimension:1150x970x650mm(LxWxH). Working platform size:1045x720mm(LxW). How to use: 1. Place the control box in a ventilated dry place where there is no dust, no moisture 4. Correctly install the Spindle motor and the heat pump. The heat pump should be covered completely in the water, then turned on the electric current tocheck whether the water-cooling system working well. Notice:the Communication interface of the control box is USB Port, this machine can only work with Win XP 32Bit / Win 7 32Bit / Win XP 64 Bit / Win 7 64 Bit PC system. Frame Material:The whole machine used 6061 aluminum profiles Max. Feeding height:=140mm(From base of Z axis to platform) X, Y, Z Working Area:600x900x150mm Sliding unit: X axis:SFU1605 Ball Screws; Y axis:SFU1605 Ball Screws; Z axis:SFU1204 Ball Screws Drive unit: X axis:ø20 High intensity round rail, Y axis: SBRø20 high-strength aluminum base rails; Z axis: ø12 high-strength round rail Stepping motor:two-phase 3A (with handwheels) Driving Power for Stepping motor:AC110,240W, Output DC24V10A Maximum Idle speed:1500mm/m Working Speed:50-1500mm/min (different material with different speed settings) Spindle motor:2200Whigh-speed variable frequency spindle motor, ER20 chuck, matching 6mm bur 1, Water cooled spindle motor can work longer time than air cooled motor. Variable-frequency Drive(VFD):AC110V, 2200W, 0-400Hz(built-in Control box) tips:1, The spindle motor must connect with the VFD. 2, It cannot directly connect with the supply voltage (AC110V/220V). Drive of Stepping motor 0-3.5A adjustable four-axis drive(TB6560AHQchip, 24V power supply, 2,4,8,16Subdivisionsettings, Factory setting:8subdivided) Repositioning precision:=0.05mm Speed:0-24000r/m Cooling method:Water cooling, Matching heat dissipation water pump Spindle precision:Radial runout=0.03mm Carving command:G code/TAB file/nc/TAB /NCC/file Protection:Emergency stop button Communication interface:through USB PORT connect with computer support environment:Windows XP / win7 with 32bite Input Volts: AC110V Gross weight of machine :About 145kg/320lb Update function: with limit switch. Woodworking industry: sculpture, round carving, wooden handicraft processing Advertising signs: logo making, cutting acrylic, plastic molding, suit for making a variety of materials advertising decorative products Other industries: The engraver could do shadow-carved, sculpture which widely used in the gift industry; can be used in aluminum cutting industry, such as aluminum, aluminum-plastic plate, aluminum honeycomb panels, aluminum, 3D engraving process, Artificial plate, cutting LED and neon letter, making plastic light box model; also can engrave on acrylic, copper, PVC board, artificial stone, MDF board, and other metal sheet. 1, The NEW 2.2KW water-cooled VFD is available operating for long time, which can reinforced the processing ability of the machine and can be used to engrave on aluminum alloy and hard wood. 3, High quality accurate ball Screws drive make the engraving more precision. USB Installment HANDWHEEL Description: Waterproof design, very durable, anti-dirt, oil spray Power by USB port Dimensions: 22 x 8 x 3cm The usb self-check light, you can type the ” scroll” on the keyboard to activate it. Directional motion control: X+, X-, Y+, Y-, Z+, Z-, A+, A- Feed rate control: F+, F- Jog rate: J+, J- Spindle speed: speed up, slow down Programming: E-stop, cycle start, spindle on/off, Redo, single step, original point Package Include 1 Remote controller 1 Cable. Feedback is very important to us. It is impossible to address issues if we do not know about them! Faction is our ultimate goal. We work hard to earn your trust and future business. A If you receive a defective item, you may return it or ask for a discount. Due to time zones, our reply to your questions may not be immediately. If it’s non-workdays, please kindly be patient and wait till Monday.
