SM32V Milling and Drilling Machine – Benchtop Mill Drill with Digital Readout 1.5KW Brushless Motor R8 Taper. The SM32V milling and drilling machine is a versatile benchtop metalworking unit designed for precision drilling, milling, and facing operations in workshops and small production facilities. Equipped with a 1.5-kilowatt brushless motor and variable spindle speed from 50 to 2250 revolutions per minute, this machine handles a wide range of materials including steel, aluminum, and brass with consistent results. ±90° (The nose can actually rotate 360 degrees). Distance from spindle to table. The Range of spindle speeds. 33.1″8.3″ (840mm210mm). Milling machine:215 kg (474 lbs) / 257 kg (567 lbs) Supporting base:30 kg (66 lbs) / 46 kg (101 lbs). Axis X power feed voltage. Axis X power feed Power. Axis X power feed speed range. Precision of grating ruler. Package Dimensions (PART 1). 106 x 71 x 118 cm (41.7″ x 28.0″ x 46.5). Package Dimensions (PART 2). 73 x 51 x 78 cm (28.7″ x 20.1″ x 30.7). Product Features & Advantages. Precision 3-Axis Digital Readout System. The integrated 3-axis digital readout system displays real-time position data for longitudinal, cross, and vertical table movements on a compact liquid crystal display mounted at the front of the machine. This eliminates manual counting of handwheel rotations and allows operators to achieve precise positioning with repeatability of 0.01 millimeters. The digital display is backlit for clear visibility in workshop environments and can be zeroed at any position for relative measurement work. Variable Speed Control with Dual Gauges. The front control panel features a large analog speed gauge that displays the current spindle speed from 50 to 2250 revolutions per minute, along with a digital depth gauge that shows the spindle quill position in millimeters. A rotary speed adjustment knob allows smooth, stepless speed changes to match the cutting requirements of different materials and tooling diameters. The panel also includes a prominent red emergency stop button and forward/stop/reverse switches for safe, intuitive operation. Automatic X-Axis Power Feed – Smoother Cuts, Less Fatigue. Equipped with an X-axis power feed unit, the table travels automatically at a steady, adjustable speed – eliminating uneven manual cranking and delivering a more consistent surface finish. With variable speed control and rapid traverse in both directions, you can match the feed rate to different materials and cutters, then quickly return the table for the next pass. It reduces operator fatigue on long milling jobs, while the manual handwheel remains available for precise positioning and fine adjustments. Powerful 1.5KW Brushless Motor. The machine is driven by a high-performance 1.5-kilowatt brushless direct current motor that delivers smooth, consistent torque across the entire speed range. Unlike conventional brushed motors, the brushless design eliminates brush wear and sparking, resulting in longer motor life, reduced maintenance, and cleaner operation. The motor is paired with an electronic speed controller that maintains constant speed under varying loads, preventing stalls during heavy cuts. A cast aluminum motor housing with cooling fins dissipates heat efficiently during extended operation, ensuring reliable performance in demanding workshop environments. Large Work Table with Three T-Slots. The generously sized 840 by 210 millimeter cast iron work table provides ample surface area for securing workpieces of various sizes using standard clamps and fixtures. Three precision-machined 14-millimeter T-slots run the full length of the table, allowing flexible positioning of workholding accessories. The table surface is precision-ground to ensure flatness and features engraved millimeter scales along both axes for quick reference when positioning workpieces. 3-Spoke Spindle Feed Handwheel – Precise, Effortless Drilling Control. The front-mounted 3-spoke handwheel gives you smooth, direct control over the spindle’s vertical feed. Its long handles provide excellent leverage, making drilling operations effortless while allowing fine, sensitive feed adjustments for different materials and drill sizes. A graduated dial on the hub lets you set and repeat drilling depths with accuracy, so every hole comes out consistent. Whether peck drilling or making a single pass, the handwheel delivers the tactile feedback and precision that manual machining demands. All machine controls are positioned for comfortable, intuitive operation. The longitudinal and cross-feed handwheels are located at the front of the table for easy access, while the vertical feed handle is positioned on the right side of the column. Chrome-plated handwheels with precision-machined aluminum grips provide smooth, comfortable operation during extended machining sessions. The speed control knob and emergency stop button are grouped on the front panel within easy reach, while the digital readout display is mounted on an adjustable arm that can be positioned for optimal viewing angle. Heavy-Duty Cast Iron Construction. The machine is built on a robust cast iron base, column, and head that provide exceptional rigidity and vibration damping for accurate, chatter-free cutting. The substantial weight of 215 kilograms ensures the machine remains stable during heavy cuts without the need for additional bolting to the floor. All precision surfaces including the table, column ways, and spindle quill are ground and honed to tight tolerances for smooth, accurate movement. The durable particle-coated finish resists scratches, chips, and corrosion, maintaining a professional appearance in workshop environments for years of reliable service. Large Cross-Feed Handwheel with Precision Scale – Accurate Positioning Made Easy. The large-diameter cross-feed handwheel features a free-spinning crank handle for smooth, comfortable table movement along the Y axis. A clearly marked graduated scale above the saddle provides instant position reference, making it easy to locate, repeat, and verify machining coordinates at a glance. Adjustable travel stops and locking levers let you limit table movement or secure the axis firmly in place – ideal for repetitive cuts and consistent, accurate results across multiple workpieces. Powerful function: This is a multi-functional drilling and milling machine, can complete drilling and milling operations. Also can be used for precision parts processing, sample processing and model. Three axis grating ruler: Three axis grating ruler includes zero clear, preset, inch/metric display, relative/absolute switch, automatic sub-centers, calculator, power failure memory, RI and other functions, greatly improve the processing efficiency and accuracy! All metal: It uses an integrated spindle and brass gear, which makes it not only precise but also durable. Variable-Speed: Whether you need high speed or lower speed spindle operations this machine can handle it. Boasting a 50-2250 RPM spindle speed for the extreme precision your project needs. Ergonomic Controls: Chrome-plated handwheels, grouped control panel, and adjustable digital display arm reduce operator fatigue during extended use. Unpacking and Setup: Remove the wooden crate from around the machine. Unbolt the machine from the crate bottom using the proper lifting equipment. Clean all rust-protected surfaces with a mild commercial solvent, kerosene, or diesel fuel. Do not use paint thinner, gasoline, or lacquer thinner as these will damage painted surfaces. Cover all cleaned surfaces with a light film of machine oil. Assembly: Assemble the machine according to the included manual. Install the digital readout display on its mounting arm. Mount the drill chuck onto the spindle taper and secure with the M12 drawbar. Connect the power cord to a properly grounded AC 110V / 60Hz outlet. Lubrication: Fill all oil cups and grease fittings with the recommended lubricants before the first use. The table ways, lead screws, and spindle quill require regular lubrication for smooth operation and long service life. Workpiece Setup: Secure the workpiece to the table using appropriate clamps, vises, or fixtures. Ensure the workpiece is firmly held and will not move during cutting. Use parallels when necessary to support the workpiece properly. Speed Selection: Select the appropriate spindle speed for the material and tooling being used. Use lower speeds for larger diameter tools and harder materials. Use higher speeds for smaller tools and softer materials. Adjust the speed using the rotary control knob while monitoring the speed gauge. Machining Operation: Set the digital readout to zero at the reference position. Advance the spindle or table to the starting position. Engage the feed and begin the cut. Use appropriate feed rates to avoid excessive tool wear or workpiece damage. Apply cutting fluid when machining steel or other ferrous metals. WARNING: This machine has rotating cutting tools and moving parts that can cause serious injury. Read the entire manual before setup or operation. Training: This machine is designed for use by properly trained and experienced personnel only. Do not operate until proper training and knowledge has been obtained. Guards: Keep all safety guards in place and in working order. Do not remove or bypass any safety devices. Tooling: Remove all adjusting keys and wrenches from the machine before turning on the power. Check that any adjusting wrenches are removed from the tool or spindle. Unintentional Starting: Make sure the power switch is in the OFF position before plugging in the tool. Always disconnect the machine from the power source before adjusting or servicing. Do Not Force: Do not force the tool or attachment to do a job for which it was not designed. Always use the tool at the rate for which it was designed. Work Area: Keep the work area clean and well-lit. Cluttered areas and benches invite accidents. Do not use in damp or wet locations. Power Off: Never leave the machine running unattended. Turn the power off and wait for all moving parts to stop before leaving the machine. Apparel: Wear proper apparel. Loose clothing, gloves, neckties, rings, bracelets, or other jewelry may get caught in moving parts. Wear protective hair covering to contain long hair. Do not wear any type of glove when operating this machine. Eye Protection: Always use safety glasses. Everyday glasses only have impact resistant lenses; they are not safety glasses. Children: Keep children and visitors away. All visitors should be kept at a safe distance from the work area. Make the workshop child proof by using padlocks, master switches, and removing starter keys. Drilling and milling machine 1. Axis X power feed 1. Milling chuck set 1. Drill chuck retaining pin 1. Drill chuck wrench 1. You can make order with no worry. Any concern just feel free to let us know, we’ll reply in 24 hours in normal condition. Orders are processed from Monday-Friday; Not on the weekends & public holidays. We will work with you to get the case resolved in the fastest method. Hope for your understanding. Please contact with us at first for more details. Defective & Damaged Products. If product was received damaged or not as described, please send us some pictures or videos, so we could well understand your problem, then solve them for you ASAP. Besides, it’s much helpful for us to claim with UPS, remind our related department to pay much more attention to packaging later on. If an item is received damaged, customer service must be contacted within 7 days of receiving your item. ECheck Issues: Payments via eCheck do not clear immediately. Usually you will wait 5-7 days after checkout for it to clear.
