AG90 BT40 ER11 90° Angle Head · CNC Milling Cutter Side Milling Head 1:1 Ratio 5000RPM. [BT40 Precision Shank] Ground 7:24 taper for perfect spindle fit and automatic tool changer compatibility. [360-Degree Rotation] Full continuous rotation with engraved scale for multi-directional machining without repositioning. [ER11 Collet System] Standard ER11 output accepts tools from 1mm to 7mm diameter with excellent runout accuracy. [40Cr Alloy Steel] Full heat-treated construction ensures maximum rigidity, durability, and dimensional stability. [1:1 Direct Drive] Spiral bevel gears transmit full 12Nm torque and 1.5KW power at 5000 RPM maximum speed. [Grease Lubrication] Sealed-for-life bearing arrangement with grease lubrication for 1000-hour service interval. [Left/Right Rotation] Reversible rotation direction compatible with clockwise and counter-clockwise spindle operation. [Complete Tool Set] Includes wrenches, mounting block, pull stud, and storage case for immediate use. Overview: This AG90 BT40-ER11-80-70 90° Angle Head is a precision-engineered accessory that converts vertical spindle rotation to horizontal orientation on CNC machining centers. Built from high-grade 40Cr alloy steel with full heat treatment, it delivers exceptional rigidity and accuracy for side milling, slotting, face milling, and contouring. The 1:1 direct drive transmits full spindle speed and torque without reduction, ensuring maximum cutting efficiency. Featuring a precision-ground BT40 taper shank and ER11 collet output (tool Ø up to 7mm), the integrated 360° continuous rotation allows positioning at any angle around the vertical axis, expanding the capability of standard VMCs. With 5000 RPM and 12 Nm torque, it suits steel, aluminum, and alloy materials in mold, aerospace, automotive, and general precision engineering. 90 Degree Angle Head for CNC Milling. BT40 (7:24 Taper, Precision Ground). ER11 (Max Tool Diameter 7mm). 1:1 Direct Drive. Left / Right (L/R Reversible). 90 Degrees (Precision Spiral Bevel Gears). 40Cr Alloy Structural Steel (Full Heat Treated). Grease Lubrication (Sealed For Life). 360 Degrees Continuous Rotation. 178.7 x 65.5 x 65.5 mm (7.0″ x 2.6″ x 2.6). Net Weight / Gross Weight. 4.9 kg (10.8 lb) / 8 kg (17.6 lb). 46 x 39 x 27 cm (18.1″ x 15.4″ x 10.6). Read all safety instructions before use. Rotating machinery and sharp cutting tools can cause severe injury. Trained Personnel Only: This angle head is for use by qualified machinists and CNC operators only. Do not operate without proper training. Never Exceed Rated Speed: Do not exceed 5000 RPM. Excessive speed can cause bearing failure, gear damage, and catastrophic tool breakage. Never Exceed Rated Torque: Do not exceed 12 Nm. Overloading the gear train causes permanent damage. Secure Locking: Ensure rotation lock screws are fully tightened before machining. A loose head can rotate during cutting. Pull Stud Tightness: Verify pull stud torque before each use. Loose stud can cause head separation from spindle. Taper Surface Protection: Keep BT40 taper clean and undamaged. Scratches cause runout and vibration. Proper Tool Installation: Ensure cutting tools are seated and ER11 nut tightened. Loose tools can eject at high speed. Guards and Enclosures: Always operate with machine guards closed. Never reach into machining area while spindle rotates. Coolant and Chips: Use appropriate coolant directed at cutting zone. Hot chips can cause burns; wear safety glasses. Inspection Schedule: Inspect before each use for wear, damage, or loose fasteners. Stop immediately if abnormal noise/vibration occurs. Storage: Store in clean, dry environment. Apply rust preventive oil to precision surfaces. Do not stack heavy objects. No Modifications: Do not modify, disassemble, or repair. Precision BT40 Taper Shank Input. Precision-ground BT40 7:24 taper, strict accuracy for perfect concentricity and repeatability. Maximum contact area, excellent torque transmission, minimal runout. Integrated pull stud for ATC integration, stable cutting up to 5000 RPM. 360° Continuous Rotation with Scale. Precision-machined graduated scale ring encircles blue anodized body. Full 360° rotation, lock at any angle. Fine markings 0-350° for multi-directional machining, reduces setup time, expands working envelope. ER11 High-Precision Collet Output. Standard ER11 collet system, tool Ø 1-7mm. Excellent gripping force and runout accuracy. ER11A spanner wrench included. Dynamically balanced for 5000 RPM, minimizes vibration. 40Cr Alloy Steel · Full Heat Treatment. Entire body and gears from 40Cr chromium-alloy steel. Quenched and tempered for hardness and toughness. Case-hardened spiral bevel gears, smooth power transmission, minimal backlash. 1:1 Direct Drive · High Torque. Precision 1:1 spiral bevel gear pair delivers full spindle power (12 Nm, 1.5 KW) without reduction. Greater tooth contact, quieter operation, higher load capacity, 1000-hour service life. Complete Professional Tooling Set. Includes ER11A spanner, 17mm open-end wrench, mounting block, pre-installed pull stud, durable storage case. Ready for immediate installation and operation. ITEM OPERATING INSTRUCTION. Clean BT40 taper, check ER11 chuck rotates freely. Install the Pull Stud: Tighten pull stud to specified torque. Loose stud can cause disengagement and injury. Set the Output Angle: Loosen lock screws with 17mm wrench, rotate head to desired angle using scale, tighten firmly. Mount in Machine Spindle: Clean spindle bore, load angle head via ATC or manual insertion. Verify taper fully seated. Install the Cutting Tool: Insert ER11 collet and tool, thread nut by hand, tighten with ER11A spanner. Program and Machine: Set spindle speed? 5000 RPM. Program appropriate feeds and depths. Use coolant as recommended. After Operation: Stop spindle, retract tool, remove angle head, clean taper, apply rust preventive oil. Remove tool and store separately. ITEM INCLUDED (057287). AG90-BT40-ER11-80-70 Angle Head Main Unit 1. ER11A Collet Spanner Wrench 1. 17mm Open-End Wrench 1. Mounting Support Block 1. BT40 Pull Stud 1. You can make order with no worry. Any concern just feel free to let us know, we’ll reply in 24h. Orders processed Mon-Fri; not on weekends/public holidays. We will work with you to resolve quickly. Items must be new, unused, with all original materials. Defective & Damaged Products: Send pictures/videos for faster resolution. Contact within 7 days of receiving damaged item. ECheck Issues: Payments via eCheck do not clear immediately.
